IC660BLM508 终端电阻 总线终端电阻

【产品详情】

GE Fanuc天才总线通信协议要求使用终端电阻，如GE Fanuc IC660BLM508 75欧姆总线终端电阻，以减少反射波信号。当终端电阻不与协议一起使用时，网络中会产生高频噪声，从而产生传输错误。GE发那科IC660BLM508 75欧姆总线终端电阻是一款75欧姆终端电阻，来自工厂，包含4个电阻，专门设计用于连接天才总线网络，减少网络中的信号反射。GE发那科IC660BLM508 75欧姆总线终端电阻是一个封装的电子元件，由碳制成，有4个连接引线，设计用于连接天才总线网络的任何一端。阻值的75欧姆值与天才总线协议的特性阻抗额定值相匹配。

GE Fanuc IC660BLM508 75欧姆母线终止电阻的连接导线没有标记，但当电阻的导线指向右侧时，很容易识别。电阻上垂直排列有4个端口，从上到下依次为SER 1、SER 2、SHD IN、SHD OUT端口。GE发那科IC660BLM508 75欧姆总线终端电阻器是一个封装组件，除了用于保护和维护它所连接的Genius I/O Block的正常程序外，不需要特殊的维护或环保措施。处理GE Fanuc IC660BLM508 75欧姆总线终端电阻时应小心，因为可能产生ESD放电。

IC660BLM508 终端电阻 总线终端电阻

【英文介绍】

The GE Fanuc Genius bus communication protocol requires the use of a terminal resistor, such as the GE Fanuc IC660BLM508 75-ohm bus terminal resistor, to reduce reflected wave signals. When the terminal resistance is not used with the protocol, high-frequency noise is generated in the network, resulting in transmission errors. The GE Fanuc IC660BLM508 75 Ohm Bus terminal resistor is a 75 ohm terminal resistor from the factory that contains 4 resistors specifically designed to connect Genius bus networks and reduce signal reflection in the network. The GE Fanuc IC660BLM508 75-ohm bus terminal resistor is a packaged electronic component, made of carbon, with 4 connection leads, designed to connect either end of the Genius bus network. The 75 ohm value of the resistance matches the characteristic impedance rating of the Genius Bus protocol.

The GE Fanuc IC660BLM508 75 ohm bus-terminating resistor's connection wire is not marked, but it is easy to identify when the resistor's wire is pointing to the right. There are four ports vertically arranged on the resistor, which are SER 1, SER 2, SHD IN, and SHD OUT ports from top to bottom. The GE Fanuc IC660BLM508 75 Ohm bus terminal resistor is a packaged component that requires no special maintenance or environmental measures other than the normal procedures used to protect and maintain the Genius I/O Block to which it is connected. Care should be taken when handling GE Fanuc IC660BLM508 75 ohm bus terminal resistors, as ESD discharge may occur.
