IC660BLC003 预制电缆 配套连接器尺寸为36英寸

【产品详情】

GE Fanuc IC660BLC003电缆为预制电缆，配套连接器尺寸为36英寸。IC660BLC003电缆是Belden 9182电缆，用于I/O块之间的布线。当IC660BLC003电缆用于连接I/O块时，电缆应连接到第一个或最后一个块，以便它可以向块的顶部出口。此外，应在串口1和串口2安装一个150欧姆的终端插头，并使用IC660BLC003电缆。GE Fanuc推荐的将总线连接到I/O块的方法是将它们直接连接到块上的终端组件上。这种公共汽车连接通常被认为是永久性的。当系统运行时，不应拆除总线连接，因为由此产生的数据错误可能导致危险的控制条件。

在任何东西被移除之前，总线应该被关闭，因为移除一个模块上的终端组件可能会导致总线连续性中断。如果总线正在控制不能关闭的关键进程，则可以通过中间连接器完成块的布线。该程序允许将总线上的终端组件移除，同时使数据完整性得以维护。拆下端子组件时，应将导线两端用胶带包住，防止不同导线之间及导线与地面之间发生短路。Genius I/O模块的工作温度额定值高达140华氏度。

IC660BLC003 预制电缆 配套连接器尺寸为36英寸

【英文介绍】

The GE Fanuc IC660BLC003 cable is a prefabricated cable with a 36-inch connector. The IC660BLC003 cable is the Belden 9182 cable for routing between I/O blocks. When the IC660BLC003 cable is used to connect I/O blocks, the cable should be connected to the first or last block so that it can exit towards the top of the block. In addition, a 150 ohm terminal plug should be installed in serial ports 1 and 2 and IC660BLC003 cable should be used. The way GE Fanuc recommends connecting buses to I/O blocks is to connect them directly to the terminal components on the block. Such bus connections are generally considered permanent. The bus connection should not be removed while the system is running, as the resulting data errors can lead to dangerous control conditions.

The bus should be shut down before anything is removed, as removing a terminal component on a module can cause a break in bus continuity. If the bus is controlling a critical process that cannot be closed, the wiring of the block can be done through an intermediate connector. The program allows the terminal components on the bus to be removed while data integrity is maintained. When removing the terminal assembly, wrap both ends of the conductor with tape to prevent short circuits between different conductors or between the conductor and the ground. The Genius I/O modules are rated for operating temperatures up to 140 degrees Fahrenheit.

IC660BLC003 预制电缆 配套连接器尺寸为36英寸
