IC693CBK002 专用线缆套件

【产品详情】

IC693CBK002线缆套件是GE系列90-30高密度模块的专用线缆套件。该电缆套件由GE发那科自动化公司设计和制造。这个特定的套件包括2根用于连接到模块的电缆，这些电缆每根都有一个右端连接器和一个左端连接器。这些电缆的特定连接器是一个24针连接器，它用于使用终端块快速连接(TBQC)组件的特定32点I/O模块。GE发那科自动化IC693CBK002电缆套件中包含的两根电缆长度均为1米。这些电缆提供了从模块到安装在终端块组件上的连接器的连接。

GE发那科自动化IC693CBK002电缆套件电缆是引脚对引脚布线。电缆接头上的每根导体提供1.2安培的额定电流。当使用带16点输出模块的电缆时，需要使用1.2安培的较低电流值作为最大负载额定电流。对于要求额定电流高于1.2安培的现场设备，不能使用TBQC组件。相反，标准端子板本身就可以足够有效地工作。GE Fanuc Automation IC693CBK002电缆套件电缆具有90度连接器。这两根电缆都是相同的，其中2根电缆的目的是为了匹配32点I/O模块所需的连接器。线缆连接器可以从模块表面延伸2英寸。

IC693CBK002 专用线缆套件

【英文介绍】

The IC693CBK002 cable kit is a special cable kit for GE series 90-30 high-density modules. The cable kit was designed and manufactured by GE Fanuc Automation. This particular kit includes 2 cables for connecting to the module, each of which has a right end connector and a left end connector. The specific connector for these cables is a 24-pin connector, which is used for a specific 32-point I/O module using a terminal block Rapid connection (TBQC) component. The two cables included in the GE Fanuc Automation IC693CBK002 cable kit are each 1 meter in length. These cables provide a connection from the module to the connector mounted on the terminal block assembly.

GE Fanuc Automation IC693CBK002 Cable Kit Cable is pin-to-pin wiring. Each conductor on the cable connector provides a rated current of 1.2 amps. When using a cable with a 16-point output module, a lower current value of 1.2 amps is required as the maximum load rating. TBQC components cannot be used for field equipment requiring a rated current higher than 1.2 amps. In contrast, the standard terminal board itself can work efficiently enough. GE Fanuc Automation IC693CBK002 Cable Kit Cable with 90-degree connector. Both cables are identical, and 2 of them are designed to match the connectors required for a 32-point I/O module. The cable connector extends up to 2 inches from the module surface.
