IC693CBK001 电缆套件 GE系列90-30

【产品详情】

IC693CBK001电缆套件是由GE发那科自动化设计和制造的电缆套件。该套件包含在GE系列90-30中。该电缆套件由直角连接的高密度I/O电缆组成。高密度电缆旨在为高压电路提供安全连接。该电缆套件设计用于使用来自同一制造商和系列的高密度I/O模块。GE发那科自动化IC693CBK001线缆套件包含2对线缆，分别为左侧线缆IC693CBL327和右侧线缆IC693CBL328。这2根电缆专门用于通过位于模块前面的两个24针连接器连接32点I/O模块。这些连接器电缆在一端有一个24针连接器，另一端有一组剥离的端。24个引脚或导体中的每一个都有1.2安培的额定电流。当与16点输出模块一起使用时，需要修改该电流额定值。

GE Fanuc Automation系列90-30 IC693CBK001电缆套件在使用通用端子块或带安装后或使用直接安装方法连接到I/O模块时非常有用。此外，对于带有双24针连接器的模块，这对电缆是有用的。GE Fanuc Automation IC693CBK001电缆套件的右侧和左侧I/O电缆长度均为3米。这些直角连接器电缆是为了取代以前安装在I/O模块左右两侧的旧直连接器电缆而制作的。与本线缆套件最兼容的GE系列90-30 32点I/O模块是IC693MDL654、655、752和753 GE系列90-30 I/O模块。

IC693CBK001 电缆套件 GE系列90-30

【英文介绍】

The IC693CBK001 cable kit is a cable kit designed and manufactured by GE Fanuc Automation. The kit is included in the GE Series 90-30. The cable kit consists of high-density I/O cables connected at right angles. High-density cables are designed to provide secure connections to high-voltage circuits. The cable kit is designed to use high-density I/O modules from the same manufacturer and family. The GE Fanuc Automation IC693CBK001 cable kit contains two pairs of cables, the left cable IC693CBL327 and the right cable IC693CBL328. These two cables are specifically designed to connect 32-point I/O modules via two 24-pin connectors located on the front of the module. These connector cables have a 24-pin connector on one end and a set of stripped ends on the other end. Each of the 24 pins, or conductors, has a rated current of 1.2 amps. This current rating needs to be modified when used with a 16-point output module.

GE Fanuc Automation Series 90-30 IC693CBK001 Cable kits are useful when connected to I/O modules after installation using a general purpose terminal block or tape or using the direct mounting method. Also, for modules with dual 24-pin connectors, this is useful for cables. The GE Fanuc Automation IC693CBK001 cable kit has a right and left I/O cable length of 3 meters. These right Angle connector cables were made to replace the old straight connector cables that were previously installed on the left and right sides of the I/O module. The GE Series 90-30 32-point I/O modules that are most compatible with this cable kit are the IC693MDL654, 655, 752, and 753 GE Series 90-30 I/O modules.
