IC693BEM341 工厂仪表协议兼容模块 总线控制器

【产品详情】

IC693BEM341是一个工厂仪表协议(FIP)兼容模块，属于艾默生自动化的系列90-30可编程逻辑控制器(PLC)系列，以前由GE发那科自动化制造。该模块是对以前的总线控制器的升级，因为IC693BEM341具有2.5 MHz的数据速率。IC693BEM341特别具有三(3)个内置通信接口，两个(2)个9针d壳FIP总线连接器和一个(1)RS485通信接口，用于通过固件修改进行软件升级。该模块还安装了六(6)个LED状态指示灯，如模块OK，运行，载波检测通道1;信道2的载波检测信道1使能传输，信道2使能传输。该FIB总线控制器模块设计用于通过FIB总线到FIP总线接口与90-70系列PLC等各种设备进行接口;现场控制站通过现场控制I/O模块通过现场总线接口单元(BIU);远程I/O滴通过FIP远程I/O扫描模块和通用设备使用FIP接口模块。IC693BEM341需要一个8.0或更高版本的90-30系列CPU。对于配置，该模块需要使用手持编程器(HHP)， windows编程软件IC641CTLxxx Release 2.0或更高版本，或FBCLOAD配置实用程序来下载有效的配置到模块。该模块增加的功能包括显示固件版本、最多1024个布尔值的时间戳和模式30，其中包括冗余、从I/O设备管理、时间戳、消息传递服务、MIPS同步交换和外部配置接收。

IC693BEM341控制器是GE发那科公司设计制造的FIP总线控制器。该部件属于GE系列90-30。这种特定的控制器模型是对旧的总线控制器的升级，它包括不同的创新功能。当将该型号与GE 340控制器等旧型号进行比较时，除了新的IC693BEM341型号的网络速度有所提高外，它们在功能上是相同的。GE Fanuc IC693BEM341 FIP总线控制器是总线控制器的2.5兆赫版本。它也适用于固件版本3.01。该总线控制器需要任何版本8.10或更高版本的IC693 PLC CPU。该现场总线控制器的另一个配置要求是它需要一个手持编程器或HHP。本HHP有一个由Windows开发的编程软件，应该是2.0或更高版本。必须使用FBCLOAD配置实用程序来配置控制器，使其与网络一起正常运行。

GE Fanuc IC693BEM341 FIP Bus控制器支持Configuration Mode 30。该模式是先前总线控制器版本的配置模式11的扩展，它为从设备(包括I/O巢、驱动器、plc和控制站)添加了不同的功能，如冗余、管理和监控功能。它还可以为布尔值加上时间戳，并通过FIP网络处理消息传递服务和接收外部配置。GE Fanuc IC693BEM341 FIP总线控制器中提供的一些更正是为了解决先前的问题，该问题产生了模块丢失故障，当没有此类故障时，PLC CPU报告了该故障。另一个已经纠正的问题是PLC应用程序的状态经常被错误地确定。

IC693BEM341 工厂仪表协议兼容模块 总线控制器

【英文介绍】

The IC693BEM341 is a Factory Instrumentation Protocol (FIP) compatible module that belongs to Emerson Automation's series 90-30 Programmable Logic controller (PLC) family, previously manufactured by GE Fanuc Automation. The module is an upgrade over the previous bus controller, as the IC693BEM341 has a data rate of 2.5 MHz. The IC693BEM341 in particular has three (3) built-in communication interfaces, two (2) 9-pin D-shell FIP bus connectors and one (1)RS485 communication interface for software upgrades via firmware modifications. The module is also equipped with six (6) LED status indicators, such as module OK, Run, carrier detection channel 1; Carrier detection for channel 2 Enables transmission on channel 1 and transmission on channel 2. The FIB bus controller module is designed to interface with various devices such as 90-70 series PLC through FIB bus to FIP bus interface. Field control station through the field control I/O module through the field bus interface unit (BIU); Remote I/O drops through FIP remote I/O scanning modules and universal devices using FIP interface modules. The IC693BEM341 requires a 90-30 series CPU version 8.0 or higher. For configuration, the module requires the use of a Handheld programmer (HHP), windows programming software IC641CTLxxx Release 2.0 or later, or the FBCLOAD Configuration utility to download a valid configuration to the module. Added features in this module include displaying firmware versions, timestamps of up to 1024 Booleans, and mode 30, which includes redundancy, slave I/O device management, timestamps, messaging services, MIPS synchronous exchange, and external configuration reception.

The IC693BEM341 controller is a FIP bus controller designed and manufactured by GE Fanuc. This part belongs to the GE series 90-30. This particular controller model is an upgrade over the old bus controller, and it includes different innovative features. When comparing this model with older models such as the GE 340 controller, they are functionally identical except for the improved network speed of the new IC693BEM341 model. The GE Fanuc IC693BEM341 FIP bus controller is a 2.5 MHZ version of the bus controller. It is also available with firmware version 3.01. The bus controller requires any version 8.10 or later of the IC693 PLC CPU. Another configuration requirement for this fieldbus controller is that it requires a handheld programmer or HHP. This HHP has a programming software developed by Windows, which should be version 2.0 or later. The FBCLOAD configuration utility must be used to configure the controller to work properly with the network.

The GE Fanuc IC693BEM341 FIP Bus controller supports Configuration Mode 30. This mode is an extension of the previous bus controller version of Configuration Mode 11, which adds different features such as redundancy, management, and monitoring functions to slave devices, including I/O nests, drives, PLCS, and control stations. It can also timestamp Boolean values and handle messaging services and receive external configurations over the FIP network. Some of the updates provided in the GE Fanuc IC693BEM341 FIP bus controller are designed to address a previous issue that produced a module loss fault that was reported by the PLC CPU when there was no such fault. Another problem that has been corrected is that the status of PLC applications is often incorrectly determined.
