IC693BEM321 I/O链路主模块卡

【产品详情】

GE Fanuc IC693BEM321 I/O链路主模块卡，顾名思义，是一个串行接口卡，将从16个从模块接收的输入连接到GE Fanuc系列90-30 PLC系统中，作为这些从模块和系统cpu之间的网关。单个GE Fanuc IC693BEM321 I/O链路主模块卡可接收高达1K(1024)的数字输入，产生1K的数字输出，以向现场执行器发送命令响应。该接口卡的配置是通过手持GE发那科编程器或使用专有软件完成的。

与GE Fanuc的大多数附件模块一样，IC693BEM321 I/O链路主模块卡可以插入GE Fanuc系列90-30和90-70产品线的PLC的任何可用插槽中。在GE发那科PLC底板中可以同时插入6个主模块，每个主模块代表一个独立的I/O链路来控制一个特定的扇区或部分。GE Fanuc IC693BEM321 I/O链路主模块卡的5v直流电源直接从底板连接，链路中连接的现场设备必须独立供电。支持串行通信协议RS-422和RS-485，使用相同的20针本田插座放置在模块的前面。三个状态led用来反映I/O Link接口卡的工作状态。模块中的复位按钮将在按下时打开和关闭整个链接，它用于清除系统中存在的任何故障。

 IC693BEM321 I/O链路主模块卡

【英文介绍】

The GE Fanuc IC693BEM321 I/O Link Master Module card, as the name suggests, is a serial interface card that connects inputs received from 16 slave modules to the GE Fanuc Series 90-30 PLC system, acting as a gateway between these slave modules and the system cpu. A single GE Fanuc IC693BEM321 I/O link master module card can receive up to 1K(1024) of digital input and produce 1K of digital output to send a command response to a field actuator. The configuration of the interface card is done via a handheld GE Fanuc programmer or using proprietary software.

As with most of GE Fanuc's accessory modules, the IC693BEM321 I/O link master module card can be inserted into any available slot in the PLC of the GE Fanuc Series 90-30 and 90-70 product lines. Up to six master modules can be inserted into the GE Fanuc PLC baseboard at the same time, each representing an independent I/O link to control a specific sector or section. GE Fanuc IC693BEM321 I/O link The 5v DC power supply of the main module card is directly connected from the mainboard. The field devices connected in the link must be powered independently. Serial communication protocols RS-422 and RS-485 are supported, using the same 20-pin Honda socket placed on the front of the module. Three status leds are used to reflect the working status of the I/O Link interface card. The reset button in the module will open and close the entire link when pressed, and it is used to clear any faults present in the system.

 IC693BEM321 I/O链路主模块卡
