IC693ADC311C 单槽型模块

【产品详情】

GE Fanuc IC693ADC311C模块已在GE系列90-30产品线中作为可选模块生产，可用于定制GE系列90-30 PLC系统。该可选模块是一个字母数字显示协处理器或ADC类型的可选模块。IC693ADC311C ADC模块作为GE Fanuc系列90-30系列PLC cpu的协处理器模块。它与GE simplicity 90-ADS系统特别兼容。IC693ADC311C ADC模块需要连接到操作员接口终端或某种类型的OIT。该OIT可以是PC机、终端或GE发那科接口。GE发那科生产几种不同的兼容OIT选项。当IC693ADC311C ADC模块与OIT连接时，它可以处理simplicity 90-ADS系统中的显示功能、报告功能和报警功能，是simplicity 90-ADS系统的重要组成部分。

GE Fanuc IC693ADC311C系列90-30 ADC模块是单槽型模块，这使得它易于安装在simplicity 90-ADS系统中，也节省了其他设备的空间。它由80C188微处理器供电，额定频率为8兆赫。如果需要，IC693ADC311C ADC模块可以通过前面板上的按钮进行复位。它还支持软配置。软配置意味着该模块可以配置没有跳线或拨码开关。IC693ADC311C ADC模块可以在其屏幕上支持下拉菜单和弹出窗口，并且每个屏幕最多可以容纳15个键，这些键都是用户自定义的。该ADC模块的另一个关键特性是可同步到PLC的实时日历时钟。此外，一个PLC可以承载一个以上的ADC模块，如IC693ADC311C ADC模块。该ADC模块有1个连接器和2个串行端口。一个串口可以将模块连接到计算机或串行打印机，另一个串口可以将模块连接到具有屏幕输出和键盘输入的终端。

IC693ADC311C 单槽型模块

【英文介绍】

The GE Fanuc IC693ADC311C module has been produced as an optional module in the GE Series 90-30 product line and can be used to customize GE Series 90-30 PLC systems. The optional module is an alphanumeric display coprocessor or ADC type optional module. The IC693ADC311C ADC module is the coprocessor module of GE Fanuc series 90-30 series PLC cpu. It is particularly compatible with the GE simplicity 90-ADS system. The IC693ADC311C ADC module needs to be connected to an operator interface terminal or some type of OIT. The OIT can be a PC, a terminal, or a GE Fanuc interface. GE Fanuc produces several different compatible OIT options. When the IC693ADC311C ADC module is connected to the OIT, it can handle the display function, reporting function and alarm function in the simplicity 90-ADS system, and is an important part of the simplicity 90-ADS system.

The GE Fanuc IC693ADC311C Series 90-30 ADC module is a single-slot module, which makes it easy to install in the simplicity 90-ADS system and also saves space on other devices. It is powered by an 80C188 microprocessor and is rated at 8 MHZ. If desired, the IC693ADC311C ADC module can be reset via a button on the front panel. It also supports soft configuration. Soft configuration means that the module can be configured without jumpers or dip switches. The IC693ADC311C ADC module can support drop-down menus and pop-ups on its screen, and each screen can accommodate up to 15 keys, which are customized by the user. Another key feature of the ADC module is the real-time calendar clock that can be synced to the PLC. In addition, a PLC can host more than one ADC module, such as the IC693ADC311C ADC module. The ADC module has 1 connector and 2 serial ports. One serial port can connect the module to a computer or serial printer, and the other serial port can connect the module to a terminal with screen output and keyboard input.

IC693ADC311C 单槽型模块
