IC693ACC350 电源适配器模块 冗余电源适配器

【产品详情】

GE Fanuc IC693ACC350系列90-30电源适配器模块是GE IC639冗余供电系统的冗余电源适配器。GE Fanuc IC693系列90-30冗余电源系统由冗余电源(RPS)底板和冗余电源适配器(RPSA)组成，RPS底板提供最多2个电源插槽，RPSA直接插入底板的电源插槽。IC693ACC350电源适配器模块可替代CPU底座或扩展底座上的标准30瓦24伏直流IC693PWR331大容量电源，可连接冗余电源底座。IC693ACC350电源适配器模块配备了一个完整的备用电池和一个串联端口连接器，如果它们安装在RPS底板的电源上，则无法正常工作。

存储备用电池有助于在意外断电的情况下保护PLC内存，而15针D-shell串行通信端口连接器有助于提供标准PLC串行端口功能。IC693ACC350电源适配器模块有一个连接器，连接到冗余电源底板的适配器电缆，它有一个“PWR”LED指示灯，这表明5伏直流输出是有效的。IC693ACC350电源适配器模块具有5伏直流标准输出电压，功率容量为30瓦，以及24伏直流继电器输出，功率容量为15瓦，24伏直流隔离输出，功率容量为20瓦，可为24伏直流I/O模块供电。IC693ACC350的工作输入电压范围为交流85伏~ 264伏或直流100伏~ 300伏，可通过VersaPro 2.00及以上版本的组态软件进行配置。

IC693ACC350 电源适配器模块 冗余电源适配器

【英文介绍】

GE Fanuc IC693ACC350 Series 90-30 Power adapter module is a redundant power adapter for GE IC639 redundant power supply system. GE Fanuc IC693 Series 90-30 Redundant power supply system consists of a redundant power supply (RPS) backboard and redundant power adapter (RPSA). The RPS backboard provides a maximum of two power sockets, and the RPSA is inserted directly into the power socket of the backboard. The IC693ACC350 power adapter module can replace the standard 30 watt 24 volt DC IC693PWR331 large capacity power supply in the CPU base or expansion base, and can be connected to the redundant power base. The IC693ACC350 power adapter module is equipped with a full backup battery and a series port connector, which will not work properly if they are installed on the power supply of the RPS baseboard.

Storing backup batteries helps protect PLC memory in the event of an unexpected power outage, while the 15-pin D-shell serial communication port connector helps provide standard PLC serial port functionality. The IC693ACC350 power adapter module has a connector that connects to the adapter cable of the redundant power base plate, and it has a "PWR" LED indicator, which indicates that the 5 volt DC output is valid. The IC693ACC350 power adapter module features a 5 volt DC standard output voltage with a power capacity of 30 watts, as well as a 24 volt DC relay output with a power capacity of 15 watts, and a 24 volt DC isolated output with a power capacity of 20 watts to power a 24 volt DC I/O module. The IC693ACC350 has an operating input voltage range of 85 V to 264 V AC or 100 V to 300 V DC and can be configured using VersaPro configuration software version 2.00 and above.

IC693ACC350 电源适配器模块 冗余电源适配器
