IC693ACC340 冗余电源底板

【产品详情】

GE Fanuc IC693ACC340冗余电源底板是90-30系列PLC系统的安装底板。底板上最多提供2个安装槽位，可安装2个标准IC693电源适配器。IC693ACC340 RPS底板配有0.125米电缆，用于连接冗余电源适配器模块，可以安装在IC693 PLC底板的左侧。IC693ACC340底板支持交流和直流电源，当安装到垂直表面时，它的额定满负荷输出为60摄氏度(140华氏度)，其长尺寸水平方向。

IC693ACC340 RPS底板可以用12awg或更大的导线接地，两端有环端子压接。将IC693ACC340 RPS底板与PLC底板接地时，将各环端子压接线端固定在安装螺栓头部的导电面上，将接地线的另一端固定在面板上的导电面上。IC693ACC340底板有2个I/O插槽，用于安装标准的IC693电源，电源可以是相同的目录编号或不同的类型。除了插槽，IC693ACC340底板还有附加的适配器连接电缆，连接到冗余电源适配器模块，4个LED指示灯(“PS1 OK”LED，“PS1 ACTIVE”LED，“PS2 OK”LED和“PS2 ACTIVE”LED)，一个24伏直流用户输出端子和一个状态继电器输出端子。

IC693ACC340 冗余电源底板

【英文介绍】

The GE Fanuc IC693ACC340 redundant power supply backboard is the mounting backboard for the 90-30 series PLC system. Up to 2 mounting slots are provided on the baseplate to accommodate 2 standard IC693 power adapters. The IC693ACC340 RPS baseboard is equipped with 0.125m cable for connecting redundant power adapter modules and can be installed on the left side of the IC693 PLC baseboard. The IC693ACC340 base plate supports both AC and DC power supplies, and when mounted to a vertical surface, it has a rated full-load output of 60 degrees Celsius (140 degrees Fahrenheit) with its long dimensions in a horizontal direction.

The IC693ACC340 RPS base plate can be grounded with 12awg or larger wires with ring terminals crimped at both ends. When grounding the IC693ACC340 RPS base plate with the PLC base plate, fix each ring terminal crimping terminal on the conductive surface of the mounting bolt head, and fix the other end of the ground cable on the conductive surface of the panel. The IC693ACC340 baseboard has 2 I/O slots for the installation of the standard IC693 power supply, which can be the same catalog number or a different type. In addition to the slots, the IC693ACC340 baseplate has additional adapter connection cables that connect to the redundant power adapter module, 4 LED indicators (" PS1 OK "LED," PS1 ACTIVE "LED," PS2 OK "LED and" PS2 ACTIVE "LED), One 24 volt DC user output terminal and one status relay output terminal.

IC693ACC340 冗余电源底板
