IC693ACC336 可编程逻辑控制器的辅助终端模块

【产品详情】

IC693ACC336是艾默生自动化90-30系列可编程逻辑控制器(PLC)平台的辅助终端模块，之前由GE发那科制造。该硬件是一个辅助终端块，用于运动伙伴DSM32和DSM314。它提供与模拟伺服器的远程接线连接，当配置为模拟模式时，提供螺钉端子用于将I/O信号连接到第三方伺服放大器单元和相应的I/O组件。当在模拟或数字模式下工作时，它还用于将频闪传感器，家用开关和超行程限制开关连接到DSM连接器B, C或D。

IC693ACC336的螺钉端子有不同的额定电压。具体来说，端子16-18和34-36的最大电压设计为30vdc，而其余输入端子的额定电压为5vdc。在选定的I/O端子和屏蔽或框架接地之间，建议安装金属氧化物压敏电阻(MOV)，以实现噪声抑制。输入电压和信号端子的推荐线径为14-18美国线规(AWG)，每个端子的拧紧扭矩为5英寸-磅。现场设备的电缆屏蔽应端接到标有S的辅助端子排的屏蔽端子上。

IC693ACC336支持DIN导轨和面板安装作为选项。默认情况下，该单板配置为DIN导轨安装。作为该终端一部分的组件包括PCB载体或部件号为UM45 profile 105.25的主板;2带脚的侧元件，目录编号UM 45-SEFE，带2个螺钉。当用于面板安装时，需要的组件是2个目录编号为UMK 45-SES的侧元件，带2个螺钉和目录编号为UMK- bf的安装耳。

IC693ACC336模块是GE发那科公司生产的辅助终端模块。该终端模块通常用于DSM314运动配合设备，该设备是GE发那科90-30系列PLC系统的一部分。有2种不同类型的终端模块用于连接DSM302设备，这些是辅助和伺服轴模块。运动伴侣设备通过36针连接器连接到可编程逻辑控制器或plc。此外，DSM302设备可以通过1米的IC800CBL324电缆或3米的IC800CBL325电缆连接到PLC。建议用户不要更换定制版本的线缆。GE发那科公司的IC693ACC336辅助端子模块需要连接到运动配合板左侧的2个槽位，分别为Aux Axis 3和Aux Axis 4。

IC693ACC336辅助端子模块用于DSM302设备与其他辅助设备的连接。这些器件可以是频闪灯检测器、外部开关或增量正交编码器。GE发那科90-30系列的IC693ACC336辅助端子模块带有38个连接螺钉端子。I/O端子16 ~ 18的最大推荐电压为+ 30v DC，其他端子的最大推荐电压为+ 5v DC。38个螺钉端子中有两个带S符号，其中一个必须接在接地板上。当用户需要挂载IC693ACC336辅助端子模块时，有两种选择。它完全适合于DIN导轨安装底座，尺寸如下:125 x 48 x 45毫米。当安装终端模块时，可以使用面板进行转换。

 IC693ACC336 可编程逻辑控制器的辅助终端模块

【英文介绍】

The IC693ACC336 is an auxiliary terminal module for Emerson Automation's Series 90-30 programmable logic controller (PLC) platform, previously manufactured by GE Fanuc. The hardware is an auxiliary terminal block for the motion buddies DSM32 and DSM314. It provides remote wiring connections to analog servers and, when configured in analog mode, screw terminals for connecting I/O signals to third-party servo amplifier units and corresponding I/O components. When operating in analog or digital mode, it is also used to connect strobe sensors, home switches, and over-travel limit switches to DSM connectors B, C, or D.

The screw terminals of the IC693ACC336 have different voltage ratings. Specifically, terminals 16-18 and 34-36 are designed for a maximum voltage of 30vdc, while the remaining input terminals are rated for 5vdc. Between the selected I/O terminal and the shield or frame ground, it is recommended to install a metal oxide varistor (MOV) for noise suppression. The recommended wire diameter for the input voltage and signal terminals is 14-18 U.S. Wire gauge (AWG), and the tightening torque is 5 inch-pounds per terminal. The cable shield of the field device should be terminated to the shield terminal of the auxiliary terminal block marked with S.

The IC693ACC336 supports DIN rail and panel mounting as options. By default, the board is configured for DIN rail mounting. Components that form part of the terminal include PCB carriers or motherboards with part number UM45 profile 105.25; 2 Side element with feet, catalog number UM 45-SEFE, with 2 screws. When used for panel mounting, the required components are 2 side elements with catalog number UMK 45-SES with 2 screws and mounting ears with catalog number UMK-BF.

The IC693ACC336 module is an auxiliary terminal module produced by GE Fanuc. The terminal module is typically used in the DSM314 motion coordination device, which is part of the GE Fanuc 90-30 series PLC system. There are 2 different types of terminal modules for connecting DSM302 devices, these are the auxiliary and servo shaft modules. The sports companion device is connected to a programmable logic controller or plc via a 36-pin connector. In addition, the DSM302 device can be connected to the PLC via a 1-meter IC800CBL324 cable or a 3-meter IC800CBL325 cable. You are advised not to replace the customized cable. The GE Fanuc IC693ACC336 auxiliary terminal module needs to be connected to the two slots on the left side of the motion mating board, namely Aux Axis 3 and Aux Axis 4.

The IC693ACC336 auxiliary terminal module is used to connect the DSM302 device to other auxiliary devices. These devices can be strobe lamp detectors, external switches, or incremental orthogonal encoders. The GE Fanuc 90-30 series IC693ACC336 auxiliary terminal module comes with 38 connecting screw terminals. The maximum recommended voltage for I/O terminals 16 to 18 is + 30v DC, and the maximum recommended voltage for other terminals is + 5v DC. Two of the 38 screw terminals have an S symbol, one of which must be connected to the floor. To mount the IC693ACC336 auxiliary terminal module, you have two options. It is perfectly suitable for DIN rail mounting bases with the following dimensions :125 x 48 x 45 mm. When installing the terminal module, you can use the panel for conversion.
