IC693ACC335 数字式伺服轴端子板
【产品详情】
IC693ACC335是GE发那科公司的数字式伺服轴端子板。该端子板用于将DSM连接器A和B连接到GE发那科数字伺服放大器上的相应连接器。此外,伺服板提供螺丝端子连接不同的I/O设备。GE Fanuc IC693ACC335端子板有2个连接器,每个连接器36脚。其中一个连接器被标记为DSM连接器,用户可以用电缆将其连接到DSM设备。另一个连接器标记为“SERVO”连接器,用户可以将其连接到GE发那科数字伺服放大器上。用户将需要伺服命令电缆,如IC800CBL001或002命令电缆,以实现此连接。
如果数字伺服轴不需要将IC693ACC335端子板连接到螺钉端子板的任何设备,则用户不需要端子板电缆或端子板。在这种情况下,用户可以直接将数字伺服命令电缆从数字伺服放大器连接到DSM面板。这可以通过A或B连接器完成。用户必须确保正确配置“OT Limit Sw”设置。此设置必须处于“DISABLE”位置,否则DSM无法运行。如果IC693ACC335端子板不用于断开用户I/O点,如家庭限制输入,则用户必须在DSM面板的前部插入电缆的另一端。电缆必须插入连接器A,这意味着伺服轴1或连接器B,这是伺服轴2设置。
IC693ACC335 数字式伺服轴端子板
【英文介绍】
The IC693ACC335 is a digital servo shaft terminal board from GE Fanuc. This terminal board is used to connect the DSM connectors A and B to the corresponding connectors on GE Fanuc digital servo amplifiers. In addition, the servo board provides screw terminals to connect different I/O devices. The GE Fanuc IC693ACC335 terminal board has 2 connectors, each with 36 pins. One of the connectors is labeled as a DSM connector, and users can connect it to DSM devices with a cable. The other connector is labeled a "SERVO" connector, and users can connect it to a GE Fanuc digital servo amplifier. Users will need a servo command cable, such as the IC800CBL001 or 002 command cable, to make this connection possible.
If the digital servo shaft does not require any device that connects the IC693ACC335 terminal board to the screw terminal board, the user does not need a terminal board cable or terminal board. In this case, the user can connect the digital servo command cable directly from the digital servo amplifier to the DSM panel. This can be done with either A or B connectors. You must ensure that the OT Limit Sw setting is correctly configured. This setting must be in the DISABLE position, or DSM will not run. If the IC693ACC335 terminal board is not used to disconnect user I/O points, such as home restricted inputs, the user must plug in the other end of the cable at the front of the DSM panel. The cable must be plugged into connector A, which means either servo shaft 1 or connector B, which is set for servo shaft 2.
IC693ACC335 数字式伺服轴端子板
