IC660BBD023 24伏直流额定I/O模块 配备了16个单独的电路
【产品详情】
IC660BBD023 I/O模块是GE发那科公司的24伏直流额定I/O模块。符合Ul标准，并符合不同的行业标准。它是2线制和3线制传感器兼容，是GE Genius I-O PLC系统的一部分。它配备了16个单独的电路，可以作为输入，输出或三态输入。I/O块的额定负载电流为2安培。这种智能I/O设备用于与各种输入和输出设备进行接口。它还与直流传感器和执行器设备兼容。这款Genius I/O设备具有开放式架构，应该防止水溅、灰尘和空气污染物。它只能在室内使用。该块的正面有LED指示灯，以监控单元和I/O的状态。
对于内部通信，IC660BBD023 I/O块有两个串行端口，称为串行端口1和串行端口2。它还配备了一个盾入端口和一个盾出端口。I/O块可以通过使用连接到监视器端口的可编程控制器来配置或监控。IC660BBD023 I/O模块提供短路保护、过温保护、开关故障检测、过载检测和断线检测。该块提供10毫秒到100毫秒之间的可选输入滤波时间。在正常工作期间，IC660BBD023 I/O块在使用16个输出2安培时散发68.8瓦的热量。每个电路的稳态输出电流为2安培，输出失态漏电流为1.9毫安。操作环境温度应控制在0 ~ 60℃之间。
IC660BBD023 24伏直流额定I/O模块 配备了16个单独的电路
【英文介绍】
The IC660BBD023 I/O module is a 24 volt DC rated I/O module from GE Fanuc. Conforms to Ul standards and complies with different industry standards. It is compatible with 2-wire and 3-wire sensors and is part of the GE Genius I-O PLC system. It is equipped with 16 individual circuits that can be used as input, output or three-state input. The rated load current of the I/O block is 2 amps. This intelligent I/O device is used to interface with various input and output devices. It is also compatible with DC sensor and actuator devices. This Genius I/O device has an open architecture that should protect against water splashes, dust, and air pollutants. It can only be used indoors. The front of the block has LED indicators to monitor the status of the unit and I/O.
For internal communication, the IC660BBD023 I/O block has two serial ports, called serial port 1 and Serial port 2. It is also equipped with a shield incoming port and a shield outgoing port. I/O blocks can be configured or monitored by using a programmable controller connected to a monitor port. The IC660BBD023 I/O module provides short circuit protection, over temperature protection, switch fault detection, overload detection, and line break detection. This block provides an optional input filtering time between 10 milliseconds and 100 milliseconds. During normal operation, the IC660BBD023 I/O block emits 68.8 watts of heat while using 16 outputs of 2 amps. Each circuit has a steady-state output current of 2 amps and an output loss current of 1.9 mA. The operating environment temperature should be controlled between 0 and 60 ° C.
IC660BBD023 24伏直流额定I/O模块 配备了16个单独的电路
