IC660BBA101电阻温度检测器  具有多种诊断功能

【产品详情】

GE Fanuc Genius I/O模块目录号为IC660BBA101，是一款电阻温度检测器(RTD)模块，具有六(6)个输入电路，每组两(2)个电路。作为RTD块I/O模块，该模块用于温度应用，因为RTD传感器通常用于测量温度。此外，该模块能够接受0到5000欧姆的电阻输入。

IC660BBA101 RTD模块I/O支持铂、铜和镍RTD等RTD传感器。线性化和信号调理嵌入在RTD块I/O中，并传送到工程单元的中央处理单元(CPU)。它以十分之一摄氏度、华氏度、欧姆或计数来报告。此外，IC660BBA101 RTD块I/O能够配置告警阈值，Alpha类型和输入滤波时间。此RTD块I/O是出厂校准的，因此在设备运行过程中不需要重新校准。

IC660BBA101还具有多种诊断功能，如输入短检、内部故障检测、接线错误检测、断线检测、输入超量程和过量程指示、高、低输入告警等。故障发生可以自动报告或禁用每个通道。

IC660BBA101的分辨率为0.1摄氏度，绝对精度为典型+/-0.5°C，铂或镍最高+/-1.0°C，典型+/-5°C, 10W铜最高+/-10°C。它的软件可配置更新频率为400ms、800ms或1600ms一次，输入滤波器范围为400ms、800ms、1600ms。

IC660BBA101 RTD输入模块有2个指示灯，用于指示模块的工作状态，因此当发生故障时，Unit OK指示灯开始闪烁。

IC660BBA101 RTD输入模块具有内部故障检测、开线检测、高低输入告警等安装错误和运行错误的自动诊断功能。例如，如果一个或多个输入读数超出公差范围，内部故障检测设施会通知CPU。它还提供了低和高报警阈值，以设置特定输入通道的限制。该模块的尺寸为8.83 x 3.34 x 3.91英寸，重4磅。为了使用输入设备，RTD必须连接到输入设备的RTN和SIG端子上。手持式监视器允许用户配置参数，如活动通道，故障报告，输入滤波时间和工程单元参数。在模块内部，有一个光耦合器，用于隔离时钟信号和控制信号。IC660BBA101 RTD输入块可以上下颠倒安装，两侧有2英寸的空间，以便适当冷却。

IC660BBA101电阻温度检测器  具有多种诊断功能

【英文介绍】

The GE Fanuc Genius I/O module, catalog number IC660BBA101, is a resistance temperature detector (RTD) module with six (6) input circuits, each set of two (2) circuits. As an RTD block I/O module, this module is used for temperature applications as RTD sensors are commonly used to measure temperature. In addition, the module is capable of accepting resistance inputs from 0 to 5000 ohms.

IC660BBA101 RTD module I/O supports RTD sensors such as platinum, copper, and nickel RTDS. Linearization and signal conditioning are embedded in RTD block I/O and delivered to the engineering unit's central processing unit (CPU). It is reported in tenths of a degree Celsius, degrees Fahrenheit, ohms, or counts. In addition, the IC660BBA101 RTD block I/O can be configured with alarm thresholds, Alpha types, and input filtering times. This RTD block I/O is factory calibrated, so it does not need to be recalibrated during device operation.

The IC660BBA101 also has a variety of diagnostic functions, such as input short check, internal fault detection, wiring error detection, disconnection detection, input overrange and overrange indication, high and low input alarm, etc. Fault occurrence can be reported automatically or each channel can be disabled.

The IC660BBA101 has a resolution of 0.1 °C and absolute accuracy of typical +/-0.5°C, platinum or nickel up to +/-1.0°C, typical +/-5°C, and 10W copper up to +/-10°C. Its software can be configured to update at 400ms, 800ms or 1600ms once, and the input filter range is 400ms, 800ms, 1600ms.

The IC660BBA101 RTD input module has two indicators, which are used to indicate the working status of the module, so when a fault occurs, the Unit OK indicator starts to blink.

The IC660BBA101 RTD input module automatically diagnoses installation errors and running errors, such as internal fault detection, open line detection, and high or low input alarms. For example, if one or more input readings are out of tolerance, the internal fault detection facility notifies the CPU. It also provides low and high alarm thresholds to set limits for specific input channels. The module measures 8.83 x 3.34 x 3.91 inches and weighs 4 pounds. In order to use the input device, the RTD must be connected to the RTN and SIG terminals of the input device. The handheld monitor allows users to configure parameters such as active channels, fault reporting, input filtering times and engineering unit parameters. Inside the module, there is an optical coupler that isolates the clock signal from the control signal. The IC660BBA101 RTD input block can be mounted upside down with 2 inches of space on both sides for proper cooling.
