531X124MSDAGG1  抑制电路板 电路板上有八个孔

【产品详情】

 531X124MSDAGG1是通用电气公司生产的一款抑制电路板。531X124MSDAGG1是一个很小的电路板，没有太多的东西。531X124MSDAGG1有三个大的暗红色圆形聚酯电容器和两个大的黄色聚丙烯电容器。这些电容器用来产生一个电场，然后用来储存额外的能量供电路板使用。531X124MSDAGG1有四个分散在电路板周围的金属插孔。531X124MSDAGG1有四个带带的大浅蓝色电阻。电阻器条与彩色代码一起使用，以确定每个电阻器可以限制的能量量。每个彩色条带对应一个数字，这个数字可以用在一个方程中来确定电阻。531X124MSDAGG1有两个大的银色电阻和一个长黑色电阻。531X124MSDAGG1有一个大型变压器。变压器是一种静电装置，它通过电磁感应在两个或多个电路之间传递电能。在变压器的一个线圈中变化的电流产生变化的磁场，磁场又在另一个线圈中引起变化的电动势或“电压”。变压器有三根黑色的电线。两根电线粗，一根很细。细线固定在电路板上，而另外两根粗线则不固定。两根粗线确实有圆形小孔，末端有一个红色连接器。电路板上有八个孔。四个孔有金属边框，其余的没有边框。

531X124MSDAGG1  抑制电路板 电路板上有八个孔

【英文介绍】

 The 531X124MSDAGG1 is a suppression circuit board produced by General Electric Company. The 531X124MSDAGG1 is a very small board that doesn't have much in it. The 531X124MSDAGG1 has three large dark red round polyester capacitors and two large yellow polypropylene capacitors. These capacitors are used to generate an electric field, which is then used to store additional energy for use by the circuit board. The 531X124MSDAGG1 has four metal jacks scattered around the circuit board. The 531X124MSDAGG1 has four large light blue resistors with bands. Resistor strips are used with color codes to determine the amount of energy each resistor can limit. Each color strip corresponds to a number that can be used in an equation to determine the resistance. The 531X124MSDAGG1 has two large silver resistors and a long black resistor. The 531X124MSDAGG1 has a large transformer. A transformer is an electrostatic device that transfers electrical energy between two or more circuits by electromagnetic induction. A changing current in one coil of the transformer produces a changing magnetic field, which in turn causes a changing electromotive force or "voltage" in the other coil. The transformer has three black wires. Two wires are thick and one is thin. The thin wires are fixed to the board, while the other two thick wires are not fixed. The two thick wires do have round holes with a red connector at the end. There are eight holes in the circuit board. Four of the holes have a metal border, the rest have no border.

531X124MSDAGG1 电路板上有八个孔

【其他型号推荐】

【常见问题】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

无论您对库存，价格，故障排除还是其他方面有任何疑问，我们都能满足您的需求。请致电我们，填写我们的表格，或向我们发送电子邮件-任何适合您的方式。期待您的回音！

问：您的交货时间如何？

答：我们有很多库存商品，3-5天您将收到它。

问：你们提供保修吗？

答：是的，我们为所有剩余的部件提供1年保修。

问：您可以接受哪些付款方式？

答：通常我们在中国大陆接受T/T和人民币转账
