531X111PSHATG3 该板是整个驱动系统的关键组成部分
【产品详情】
通用电气公司开发了531X111PSHATG3卡作为电机现场控制和电源板。它是GE的531X替代驱动板和卡系列的成员。该系列的成员可以安装在许多通用电气旧的和过时的驱动器和励磁器型号。该板是整个驱动系统的关键组成部分,因为它提供了驱动操作所需的电源。使用该板还为驱动器的电机场电路提供电力。本板G3系列的交流线路MOVs安装在外部,而不是安装在板上。
该董事会的正常运作是整个董事会运作不可或缺的一部分。5vdc、15vdc、24vdc额定电源均由该卡提供。电机场电路由卡的集成脉冲变压器提供电源。在电路板上发现的三个继电器为用户提供驱动控制。RUN (K1), MAX (K2)和FIELD (K3)都可以在卡上找到。531X111PSHATG3包括许多板载调整控制。三个电位器允许用户调整和校准电流电路和反馈。它们被标记为P1 (SCALE), P2 (CFB ZERO)和P3 (CFB ADJUST)。反馈和电流信号也可以使用集成到电路板中的五个可配置跳线进行调整。
用户应满足所提供的存储和安装参数。制造商提供这些以减少对驱动器或其板的任何损坏的风险。只有经过培训的合格人员才能安装531X111PSHATG3。接线和安装指南可以在系列手册以及电路板的数据表中找到。技术支持最初由系列制造商通用电气提供。
531X111PSHATG3 该板是整个驱动系统的关键组成部分
【英文介绍】
General Electric developed the 531X111PSHATG3 card as a motor field control and power supply board. It is a member of GE’s 531X replacement series of drive boards and cards. Members of this series can be installed in a number of GE older and obsolete models of drives and exciters. This board is a key component of the overall drive system as it provides the power supplies needed for drive operation. Using this board also provides power to the drive’s motor field circuitry. G3 series of this board features MOVs for the AC line that are mounted externally rather than on the board itself.
Proper function of this board is integral to overall board operation. Power supplies rated at 5 VDC, 15 VDC, and 24 VDC are all produced by this card. Motor field circuits are provided with power supplies from the card’s integrated pulse transformer. Three relays found on the board provide users with drive controls. RUN (K1), MAX (K2) and FIELD (K3) are all found on the card. 531X111PSHATG3 includes a number of onboard adjustment controls. The three potentiometers allow users to adjust and calibrate current circuits and feedbacks. These are labelled as P1 (SCALE), P2 (CFB ZERO), and P3 (CFB ADJUST). Feedback and current signals can also be adjusted using the five configurable jumpers integrated into the board.
Provided storage and installation parameters should be met by the user. The manufacturer provided these to decrease the risk of any damages to the drive or its boards. Only permit qualified personnel who are trained to handle these drive boards to install 531X111PSHATG3. Wiring and installation guides can be found in the series manual as well as the board’s datasheet. Technical support was originally provided by the series manufacturer, General Electric.
