531X111PSHATG2该卡为驱动器提供所需的电源
【产品详情】
通用电气531X111PSHATG2板是一个电机场和电源卡。它是为531X替换系列驱动板和卡而设计的。作为替换部件，它可以安装在通用电气品牌的许多励磁器和驱动器中。所需的电源是创建与这个驱动柜的组成部分。具体来说，这种G2版本的电路板是为了在外部激励器中运行而开发的。
该卡为驱动器提供所需的电源。单板支持5vdc、15vdc、24vdc电源输出。531X111PSHATG2还包括一个集成脉冲变压器，为驱动器的电机场电路提供电源。该卡还提供三个继电器点，K1 (RUN)， K2 (MAX)和K3 (FAULT)。每个继电器点都为系统控制提供了不同的选择。还提供三个电位器供用户调整或校准电路或电流反馈。它们包括P1 (FIELD SCALE)、P2 (CFB ZERO)和P3 (CFB ADJUST)。电流和反馈信号也可以使用板上的五个跳线进行调整。
应满足任何制造商提供的与电路板相关的安装参数。这些是为了降低由于安装或操作不当而导致设备损坏或缺陷的风险。只允许经过培训的用户使用该板安装电机现场控制和电源卡。有关531X111PSHATG2板接线的完整指南，请参考系统手册和设备数据表。该单板最初由通用电气公司提供技术支持。
531X111PSHATG2该卡为驱动器提供所需的电源
【英文介绍】
The GE 531X111PSHATG2 board is an electric field and power card. It is designed for the 531X replacement series driver boards and cards. As a replacement part, it can be installed in many exciters and drives under the GE brand. The required power supply is created with the components of this drive cabinet. Specifically, this G2 version of the board was developed to run in an external driver.
The card provides the power needed for the drive. The board supports 5vdc, 15vdc, and 24vdc power output. The 531X111PSHATG2 also includes an integrated pulse transformer that provides power to the driver's field circuit. The card also offers three relay points, K1 (RUN), K2 (MAX) and K3 (FAULT). Each relay point provides a different option for system control. Three potentiometers are also provided for the user to adjust or calibrate the circuit or current feedback. They include P1 (FIELD SCALE), P2 (CFB ZERO), and P3 (CFB ADJUST). The current and feedback signals can also be adjusted using the five jumpers on the board.
The installation parameters related to the board provided by any manufacturer shall be met. These are to reduce the risk of damage or defects to the equipment due to improper installation or operation. Only trained users are allowed to use the board to install motor field controls and power cards. For complete guidance on wiring the 531X111PSHATG2 board, refer to the system manual and Device data sheet. The board was initially supported by General Electric.
531X111PSHATG2该卡为驱动器提供所需的电源
