531X111PSHAJG3 具有用于电机场电路的脉冲变压器
【产品详情】
GE端子板继电器卡531X111PSHAJG3提供驱动使用的5v dc、15v dc和24v dc电流。它还具有用于电机场电路的脉冲变压器。GE终端板继电器卡531X111PSHAJG3具有3TB的盒式MOV组件，您可以作为板更换过程的一部分进行更换。先更换GE端子板中继卡531X111PSHAJG3，再更换3TB Potted MOV组件。
3TB组件包含一条带状电缆，您必须将其从原始组件移动到新组件。将一只手放在带状电缆的接头上，另一只手放在电路板上的接头上。将连接器拉开。如果你抓住带状电缆把它们分开，可能会造成损坏。
五个安装螺钉将组件固定在安装表面上。用螺丝刀将5颗螺钉拆下，备用。同时移除安装面上的四个支撑柱。您可以使用短螺丝刀进行此操作。
标记四个孔的位置组装和使用钻头使孔。必须小心确保钻孔产生的碎片不会落在3TB或驱动器的其他部件上。操作完成后，请使用真空吸尘器清洁金属屑、灰尘和钻屑的表面和部件。当您给驱动器通电时，碎片可能会损坏组件。
531X111PSHAJG3 具有用于电机场电路的脉冲变压器
【英文介绍】
GE terminal board Relay Card 531X111PSHAJG3 provides 5v dc, 15v dc, and 24v dc currents for the driver. It also has a pulse transformer for electric field circuits. The GE Terminal Board Relay Card 531X111PSHAJG3 has a 3TB cartridge MOV assembly that you can replace as part of the board replacement process. Replace the 531X111PSHAJG3 trunk card on the GE terminal board, and then the 3TB Potted MOV component.
The 3TB component contains a ribbon cable that you must move from the original component to the new component. Place one hand on the connector of the ribbon cable and the other hand on the connector on the circuit board. Pull the connector apart. If you grab the ribbon cables and pull them apart, it could cause damage.
Five mounting screws secure the assembly to the mounting surface. Remove the five screws using a screwdriver and set them aside. Also remove the four support columns from the mounting surface. You can use a short screwdriver to do this.
Mark the location of the four holes to assemble and use the drill bit to make the holes. Care must be taken to ensure that debris from drilling does not fall on the 3TB or other parts of the drive. After the operation is complete, use a vacuum cleaner to clean the surfaces and components of metal chips, dust, and drill chips. When you power the drive, debris can damage the component.
531X111PSHAJG3 具有用于电机场电路的脉冲变压器
【其他型号推荐】
| EMERSON RFLG151M36100X0 | EMERSON EWQ4B2420 | EMERSON ZWZ06406 |
| EMERSON ECDXB125529S | EMERSON ALPFM22C18ML | Emerson PrPMC2800 8406815A01B |
| EMERSON RFLG151M36100X | EMERSON D1P3X26 | EMERSON DTX242412 |
| EMERSON ECDXB906029S | EMERSON APPND24C24M2354 | EMERSON AECT23625C |
| EMERSON ECDXB145529S | EMERSON NPPND14C24M1 | EMERSON 7T04HFD |
| EMERSON RFSF146 | EMERSON APPFM24C18ML | Emerson SP640 |
| EMERSON RFSF156 | EMERSON APPFM24C24ML | EMERSON EXGJH1030 |
| EMERSON ECDXB105529S | EMERSON EWP4B22 | EMERSON NCSEW162408 |
| EMERSON RFSF155 | EMERSON ALPFM12C12M1 | EMERSON IF182410 |
| EMERSON RFSF145 | EMERSON XPC31004B050515 | EMERSON YE241808 |
| EMERSON RFSF144 | EMERSON EWP4B20 | EMERSON ACSEW162408 |
| EMERSON RFSF154 | EMERSON EWP5B20 | EMERSON NJBEW162408 |
