531X111PSHACG2该板提供驱动所需的必要电源

【产品详情】

通用电气公司开发了531X111PSHACG2卡，用于安装在驱动器中作为电机现场控制和电源板。该卡是作为531X系列替换板的成员制造的。通用电气品牌的一系列驱动器都设计用于将该板安装在其机柜中。当安装在驱动系统中时，该板提供驱动所需的必要电源。这种特定的板被开发为G2版本，卡被开发为在外部激励器而不是驱动器内操作。

当这张卡被安装到驱动器中时，会产生三个电压。主机支持5vdc、15vdc、24vdc输出。驱动器的电机场控制电路所需的电源也通过集成脉冲变压器提供。该板包括许多可调整的功能，可以根据用户需要进行配置。六个继电器为系统控制选项的执行提供了区域。531X111PSHACG2卡还包括五个跳线和三个电位计。跳线可以调节电流和反馈信号，电位器可以校准电路和电流反馈。

设备安装必须在检查了所有提供的安装参数后才进行。通过遵守这些指导方针，可以降低设备损坏的风险。只有经过培训能处理驱动和励磁板的合格人员才能安装此卡。请务必参考设备的手册和数据表，以获得连接和安装531X111PSHACG2卡的总体指南。最初，该设备的技术支持是由电路板制造商通用电气提供的。

531X111PSHACG2该板提供驱动所需的必要电源

【英文介绍】

General Electric developed the 531X111PSHACG2 card for installation in the drive as a motor field control and power board. The card is manufactured as a member of the 531X series replacement board. A range of GE branded drives are designed to mount the board in its cabinet. When installed in a drive system, the board provides the necessary power for the drive. This particular board was developed as a G2 version, and the card was developed to operate in an external driver rather than inside the drive.

When the card is installed into the drive, three voltages are generated. The host supports 5vdc, 15vdc, and 24vdc output. The power required for the driver's electric field control circuit is also provided via an integrated pulse transformer. The board includes a number of adjustable features that can be configured according to user needs. Six relays provide areas for the execution of system control options. The 531X111PSHACG2 card also includes five jumpers and three potentiometers. Jumpers can adjust the current and feedback signals, and potentiometers can calibrate the circuit and current feedback.

Installation of the equipment must be carried out after checking all the provided installation parameters. By following these guidelines, you can reduce the risk of damage to your equipment. Only qualified personnel trained to handle drive and excitation boards should install this card. Be sure to refer to your device's manual and data sheet for a general guide to connecting and installing your 531X111PSHACG2 card. Initially, technical support for the device was provided by circuit board manufacturer General Electric.

531X111PSHACG2该板提供驱动所需的必要电源

【其他型号推荐】

【常见问题】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

无论您对库存，价格，故障排除还是其他方面有任何疑问，我们都能满足您的需求。请致电我们，填写我们的表格，或向我们发送电子邮件-任何适合您的方式。期待您的回音！

问：您的交货时间如何？

答：我们有很多库存商品，3-5天您将收到它。

问：你们提供保修吗？

答：是的，我们为所有剩余的部件提供1年保修。

问：您可以接受哪些付款方式？

答：通常我们在中国大陆接受T/T和人民币转账
