531X305NTBAPG1 应用包括串行和继电器输出
【产品详情】
531X305NTBAPG1卡是通用电气公司开发的NTB/3TB终端板。该卡最初是为531X系列替换驱动板开发的。该董事会家族的成员适合安装到GE品牌的许多驱动器中。安装后，该卡提供了对驱动器中未找到的许多接口工具的访问。应用包括串行和继电器输出，低电平模拟I/O，编码器和电源。
安装NTB/3TB端子板提供稳压电源和非稳压电源。主机驱动器可以从额定5 VDC和15 VDC的稳压电源或从额定24 VDC或120 VAC的非稳压电源中提取。用户可以配置一些板设置，以符合特定的负载要求。5V和15V编码器可以通过板上的跳线进行调整。电路板还提供七个形式A和形式C继电器输出的组合。所有集成继电器包括额定120 VAC的触点。该卡还包含四个电位器，允许缩放低电平模拟I/O。
在将设备拆下包装之前，请查看通用电气提供的安装参数。为保证单板的所有功能正常运行，只有经过培训的人员才能操作和安装单板。全面的布线指南可以在系列手册以及设备数据表中找到。制造商，通用电气，是这个终端板的原始技术支持提供商。
531X305NTBAPG1 应用包括串行和继电器输出
【英文介绍】
The 531X305NTBAPG1 card was developed by General Electric as a NTB/3TB terminal board. This card was originally developed for the 531X series of replacement drive boards. Members of this board family are suited for installation into a number of drives across the GE brand. When installed, this card provides access to a number of interfacing tools not found in the drive. Applications include serial and relay outputs, low level analog I/O, encoders, and power supplies.
Installing the NTB/3TB terminal board provides both regulated and unregulated power sources. The host drive can draw from regulated supplies rated at 5 VDC and 15 VDC or from unregulated supplies rated at 24 VDC or 120 VAC. Users can configure a number of board settings to conform to specific load requirements. 5V and 15V encoders can be adjusted with the jumpers found on the board. A combination of seven form A and form C relay outputs are also provided by the board. All integrated relays include contacts rated at 120 VAC. The card also contains four potentiometers that allow for scaling of low level analog I/O.
Before removing the device from its wrappings, please review the installation parameters provided by General Electric. To ensure that all board functions operate normally, only allow trained personnel to handle and install this board. A comprehensive wiring guide can be found in the series manual as well as the device datasheet. The manufacturer, General Electric, was the original provider of technical support for this terminal board.
