IS200CABPG1B 该设备是一个PCB或印刷电路板

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200CABPG1B是一种称为控制组件背板的器件。该设备是一个PCB或印刷电路板，是由GE或通用电气制造的Speedtronic Mark VI系列的一部分。Mark VI只是通用电气Mark生产线中许多不同系列中的一个。

IS200CABPG1B是一种多层印刷线路板。当印刷电路板插入IS200CABPG1B时，该设备使其连接。IS200CABPG1B是外部信号的接口。CABP板可接IS200RAPA、IS200DSPX、IS215GBIA、IS200BAIA等接线板。IS200CABPG1B为不同的外部接口提供连接器，例如用户控制I/O(输入和输出)、前面板仪表、配置和诊断工具、前面板键盘、端口、电源输入和端口。IS200CABPG1B具有一系列不同尺寸的连接器。IS200CABPG1B上有9个白色的长连接器端口。这些连接器端口中的五个(5)位于左侧，而最后四个(4)位于右端。IS200CABPG1B顶部边缘附近有4个连接器端口。其中两个绿色的端口位于左上方，其余两个红褐色的端口位于右上方。在IS200CABPG1B的右端，一个小部件连接到PCB上，PCB上有两个额外的连接器端口。其中一个端口是银色和金属的，另一个端口是绿色的。

IS200CABPG1B 该设备是一个PCB或印刷电路板

The IS200CABPG1B is a device called a control assembly backplane board. This device is a PCB or printed circuit board that was made to be part of the Speedtronic Mark VI series which was made by GE or General Electric. The Mark VI is just one of many different series in General Electric’s Mark line.

The IS200CABPG1B is a multi-layer printed wiring board. When printed wiring boards are inserted into the IS200CABPG1B, this device enables their connections. The IS200CABPG1B is an interface between external signals. Wiring boards such as the IS200RAPA, IS200DSPX, IS215GBIA, and IS200BAIA or others can be connected into the CABP board. The IS200CABPG1B gives connectors to different external interfaces such as user control I/O (input and output), meters for front panels, configuration and diagnostic tools, keypads for front panels, ports, inputs for power supply, and ports. The IS200CABPG1B features a range of connectors in varying sizes. Nine (9) long connector ports which are white are positioned on the IS200CABPG1B. Five (5) of these connector ports have been placed on the left while and the last four (4) are located on the right end. Four (4) connector ports are near the top border of the IS200CABPG1B. Two of these ports which are green are positioned at the upper left and the remaining two which are reddish-brown are at the upper right. On the right end of the IS200CABPG1B, one small part is connected to the PCB which has two (2) extra connector ports. One (1) of the ports is silver and metal and the other one is green.

IS200CABPG1B 该设备是一个PCB或印刷电路板

【下单请联系我们】

欢迎访问厦门雄霸

销售经理：何小姐

地址：厦门市思明区吕岭路1733号创想中心2009室

（1）24小时电子邮件回复（12小时）;

（2）对于运往亚洲以外的国家/地区，请联系卖方。

【常见问题】

无论您对库存，价格，故障排除还是其他方面有任何疑问，我们都能满足您的需求。请致电我们，填写我们的表格，或向我们发送电子邮件-任何适合您的方式。期待您的回音！

问：您的交货时间如何？

答：我们有很多库存商品，3-5天您将收到它。

问：你们提供保修吗？

答：是的，我们为所有剩余的部件提供1年保修。

问：您可以接受哪些付款方式？

答：通常我们在中国大陆接受T/T和人民币转账
