IS200CABPG1A 用于替代创新系列卡架的背板

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200CABPG1A是GE创新系列驱动器的控制组件背板PCB。

IS200CABPG1A也被称为CABP板，用于替代创新系列卡架的背板。该卡通常用作接口单元。它的特点是卡槽，其他板可以插入。然后，这些板可以与外部信号进行交互和接口。其中一些外部信号包括来自诊断工具、用户界面键盘、面板仪表、ISBus端口或来自电源的输入。CABP通常安装在创新系列卡架组件上。机架，这是单独出售，有安装点的其他pcb被插入到CABP。

IS200CABPG1A的非板连接设计使它们不会意外插入错误的连接器。CABP上的电路板连接设计类似，因此每个卡槽都是针对特定的电路板单独设置的。知道每个板在这个PCB上的位置是至关重要的，因为试图将卡强行插入错误的插槽可能最终会损坏板和卡插槽。单板上有9个连接，相当于5个槽位。1号槽位分配给BAIA板。槽位2分配给DSPX PCB。槽位3分配给ACL_板或GBIA/PBIA模块。槽4被分配给一个BIC_卡。槽5被分配给BPI_或FOSA卡。有两个插入式连接，标记为E2和E1，到GND。E4和E3插拔连接用于CCOM。J1-12接口为外部接口，J13-J21接口为插卡槽。

IS200CABPG1A 用于替代创新系列卡架的背板

The IS200CABPG1A is the control component backplane PCB for GE's innovative series of drives.

The IS200CABPG1A, also known as the CABP board, is used to replace the back of the innovative series of card holders. The card is usually used as an interface unit. It features card slots into which other plates can be inserted. These boards can then interact and interface with external signals. Some of these external signals include input from diagnostic tools, user interface keyboards, panel meters, ISBus ports, or from the power supply. CABP is typically mounted on the innovative series of bracket assemblies. The rack, which is sold separately, has mounting points for other PCBS to be plugged into the CABP.

The IS200CABPG1A's non-board connection design prevents them from accidentally inserting the wrong connector. The board connection design on CABP is similar, so each card slot is set up individually for a specific board. Knowing where each board is on this PCB is crucial because trying to force the card into the wrong slot can end up damaging the board and card slot. The board has nine connections, equivalent to five slots. Slot 1 is allocated to the BAIA. Slot 2 is assigned to the DSPX PCB. Slot 3 is assigned to the ACL_ board or GBIA/PBIA module. Slot 4 is assigned to a BIC_ card. Slot 5 is assigned to a BPI_ or FOSA card. There are two plug-in connections, labeled E2 and E1, to GND. E4 and E3 plug connections are used for CCOM. Ports J1-12 are external ports, and ports J13-J21 are card slots.
