IS200BPPBH2B 被设计为与更大的电路板一起使用

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200BPPBH2B被设计为安全I/O包或辅助板。该模型被设计为与更大的电路板一起使用。这是一块很少有元件的小板。该板附加到其主板使用四个支架和螺钉安装插入镀黄铜工厂钻孔放置在每个角落。应该注意的是，IS200BPPBH2B板的三个边缘是形状的，可能是为了给主板上的组件留出空间。

IS200BPPBH2B有两个LED(发光二极管)位于电路板边缘。该板有两个不同尺寸的垂直连接器和两个电话插孔。它还包括一个电感线圈、几个电容器、集成电路和几个晶体管。电路板表面的一个芯片是AMD内存芯片。这是位于靠近中心的板。组件已经用参考标志进行了标记。

有一个操作员界面可以与IS210BPPBH2B模型一起使用，该界面被称为HMI或人机界面。本界面是按照微软Windows NT PC操作系统设计的，它可以支持图形显示系统、客户端/服务器功能、软件界面和用于维护的控制系统工具箱。安装程序可以在通用电气的出版物中找到，参考部件号为IS200BPPBH。这包括手册和数据表。请遵循所有安全建议。GE作为原设备制造商，为IS200BPPBH2B提供全部技术支持。

IS200BPPBH2B 被设计为与更大的电路板一起使用

IS200BPPBH2B is designed as a secure I/O package or auxiliary board. The model is designed to work with larger circuit boards. It's a small board with very few components. The board attaches to its motherboard using four brackets and screw mounts inserted into brass-plated factory drill holes placed at each corner. It should be noted that the three edges of the IS200BPPBH2B board are shaped, possibly to make room for the components on the motherboard.

The IS200BPPBH2B has two leds (light emitting diodes) located on the edge of the board. The board has two vertical connectors of different sizes and two telephone jacks. It also includes an inductor, several capacitors, integrated circuits, and several transistors. One chip on the surface of the board is an AMD memory chip. This is located near the center of the board. Components have been marked with reference tags.

There is an operator interface that can be used with the IS210BPPBH2B model, which is called an HMI or Human Machine interface. This interface is designed according to the Microsoft Windows NT PC operating system. It can support the graphical display system, client/server functions, software interface, and control system toolbox for maintenance. The installer can be found in a General Electric publication with reference part number IS200BPPBH. This includes manuals and data sheets. Please follow all safety recommendations. GE, as the original equipment manufacturer, provides full technical support for the IS200BPPBH2B.

IS200BPPBH2B 被设计为与更大的电路板一起使用
