IS200BPIAG1AEB  连接到机架系统并处理各种信号

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200BPIAG1AEB是通用电气为其Mark VI系列制造的驱动桥个性接口卡。MKVI是通用电气公司发布的Speedtronic系列中最新的蒸汽/气体重型涡轮机管理系统之一。MKVI为重型涡轮机系统提供完整的控制、保护和监测，并且可适应和扩展用于各种应用。MKVI是基于一个13或21槽的VME卡机架控制模块。

IS200BPIAG1AEB提供IGBT交流驱动器的控制和电力电子设备之间的连接。IS200BPIAG1AEB设计有7个板连接器。这包括它的主要P1连接器，它连接到机架系统并处理各种信号，包括栅极驱动和分流故障信号，来自BPIA板的应用数据，以及一些桥接控制连接。该板具有其他六个雄性垂直引脚连接器(APL, BPL, CPL, AAPL, BAPL, CAPL)，可提供与A/B/C相igbt的连接。

IS200BPIAG1AEB具有三个变压器，六个晶体管和九个电阻网络阵列。它也有一个1024位的存储设备来保存修订和板信息。

IS200BPIAG1AEB有一个面板。这有助于识别机架内的板，也标有板的位置。如果插错槽位，可能会损坏单板。请遵循手册或数据表上的安装指南。

IS200BPIAG1AEB  连接到机架系统并处理各种信号

The IS200BPIAG1AEB is a transaxle personality interface card manufactured by General Electric for its Mark VI series. MKVI is one of the latest steam/gas heavy-duty turbine management systems in the Speedtronic family released by General Electric. The MKVI provides complete control, protection and monitoring for heavy-duty turbine systems and can be adapted and expanded for a variety of applications. The MKVI is based on a 13 - or 21-slot VME card rack control module.

The IS200BPIAG1AEB provides control of IGBT AC drivers and connectivity between power electronics. The IS200BPIAG1AEB is designed with 7 board connectors. This includes its main P1 connector, which connects to the rack system and handles a variety of signals, including gate drive and shunt fault signals, application data from the BPIA board, and some bridge control connections. The board features six other male vertical pin connectors (APL, BPL, CPL, AAPL, BAPL, CAPL) that provide connectivity to A/B/C phase IGBTs.

The IS200BPIAG1AEB has three transformers, six transistors, and nine resistor network arrays. It also has a 1024-bit storage device to hold revisions and board information.

The IS200BPIAG1AEB has one panel. This helps to identify the boards within the rack and also labels the location of the boards. If the board is inserted in the wrong slot, it may be damaged. Follow the installation instructions in the manual or data sheet.

IS200BPIAG1AEB  连接到机架系统并处理各种信号
