IS200BICRH1A 该板用于创新系列中压/GP型H驱动器

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200BICRH1A是GE为其Mark VI系统制造的印刷电路板组件。MKVI是成功的燃气/蒸汽轮机管理Speedtronic系列的第五个版本。自20世纪60年代马克一号发布以来，这个系列一直在使用。从那时起，通用电气使用发布时可用的最佳技术开发和改进了几个新版本的Speedtronic管理系统。Mark VI有一个基于Windows pc的操作界面，装载了通用电气的专有软件，比如他们的控制系统工具箱和simplicity图形。

IS200BICRH1A在Mark VI系统中作为桥接接口板。该板用于创新系列中压/GP型H驱动器，并提供桥接和驱动控制之间的接口。

IS200BICRH1A具有8个数字光隔离输入和输出。它有三个模拟反馈输入，包括一个在0-10V和两个在0- 20ma。标记为P1的背板连接器用于故障串、隔离I/O和桥接控制。标记为P2的背板连接器用于控制板接口和逻辑电源连接。

IS200BICRH1A包括8个继电器输出(固态)，通过CABP板路由到CTBC端子板。这些输出中的每一个都由黄色LED指示，并且与控制光学隔离。

IS200BICRH1A有两个终端板安装在前面板上。这些标着TB1和TB2。该板有两个背板连接器，18个led，两个保险丝和8个用户TP测试点。电路板有更多的测试点，它们与最终用户无关。最终用户的所有测试点都可以通过电路板前面板上的开口进入。

IS200BICRH1A 该板用于创新系列中压/GP型H驱动器

The IS200BICRH1A is a printed circuit board component manufactured by GE for its Mark VI system. The MKVI is the fifth version of the successful gas/steam turbine management Speedtronic series. This series has been in use since the release of the Mark I in the 1960s. Since then, GE has developed and improved several new versions of the Speedtronic management system using the best technology available at launch. Mark VI has a Windows PC-based interface loaded with GE proprietary software such as their control System Toolbox and simplicity graphics.

The IS200BICRH1A serves as the bridge interface board in the Mark VI system. The board is used for the innovative series medium voltage /GP type H drivers and provides an interface between bridging and drive control.

The IS200BICRH1A has 8 digital optical isolated inputs and outputs. It has three analog feedback inputs, including one at 0-10V and two at 0-20ma. The backplane connector, labeled P1, is used for fault strings, isolated I/O, and bridge control. The backplane connector labeled P2 is used for control board interfaces and logical power connections.

The IS200BICRH1A includes eight relay outputs (solid state) that are routed to the CTBC terminal board via the CABP board. Each of these outputs is indicated by a yellow LED and is isolated from the control optics.

The IS200BICRH1A has two terminal boards mounted on the front panel. These are labeled TB1 and TB2. The board has two backplane connectors, 18 leds, two fuses and eight user TP test points. Boards have more test points that are irrelevant to the end user. All test points for the end user are accessible through openings on the front panel of the board.

IS200BICRH1A 该板用于创新系列中压/GP型H驱动器
