IS200BICMH1AAA BICM模型将用于Mark V系统

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

型号为IS200BICMH1AAA，被通用电气公司标记为IGBT门驱动卡。BICM模型将用于Mark V系统。该模型配备了一个前面板，上面标有通用电气的标志，板标识，以及一个声明，显示BICM模型应该插入哪个插槽，而不会受到任何损坏。语句是“INSTALL IN SLOT 5 ONLY”。在IMOK型号上也有一个LED指示灯。

IS200BICMH1AAA模型还包含大量的用户测试点(TP)。该型号的测试点在BCIM面板第一个开口旁边标记为1A、1B、ACOM、VMG、VDCN、VDCP、VBC、VAB。在面板上的第二个开口旁边是TRG1, TRG, ACOM和DA1至DA4。该模型的测试点标记为TP1 - TP9, TP14 - TP16;模型上的这些测试点并不是模型上唯一可用的点。IS200BICMH1AAA型号上可用的其他组件有集成电路，大约100个，电阻，大约300个，电容器超过150个。也有五个电阻网络阵列和一个单一的金属氧化物压敏电阻。

关于IS200BICMH1AAA的常见问题

IS200BICMH1AAA上有哪些可用的连接器?

IS200BICMH1AAA上有两个主背板连接器和四个公松连接器。其中三个连接器被标记为POD1、POD2和POD3。

IS200BICMH1AAA是什么类型的板?

IS200BICMH1AAA型号被通用电气公司标记为IGBT栅极驱动板/卡。

IS200BICMH1AAA BICM模型将用于Mark V系统

The model is IS200BICMH1AAA and is labeled by GE as an IGBT gate driver card. The BICM model will be used for the Mark V system. The model is equipped with a front panel marked with the GE logo, board identification, and a statement showing which slot the BICM model should be inserted into without any damage. The statement is "INSTALL IN SLOT 5 ONLY". There is also an LED indicator on the IMOK model.

The IS200BICMH1AAA model also contains a number of user test points (TPS). The test points for this model are marked 1A, 1B, ACOM, VMG, VDCN, VDCP, VBC, VAB next to the first opening of the BCIM panel. Next to the second opening on the panel are TRG1, TRG, ACOM, and DA1 to DA4. The test points of this model are marked as TP1-TP9, TP14-TP16; These test points on the model are not the only points available on the model. Other components available on the IS200BICMH1AAA model are integrated circuits, about 100, resistors, about 300, and capacitors over 150. There are also five resistor network arrays and a single metal oxide varistor.

FAQ about IS200BICMH1AAA

What connectors are available on the IS200BICMH1AAA?

The IS200BICMH1AAA has two main backplane connectors and four male loose connectors. Three of the connectors are labeled POD1, POD2, and POD3.

What type of board is IS200BICMH1AAA?

The IS200BICMH1AAA model is labeled by General Electric as an IGBT gate driver board/card.

IS200BICMH1AAA BICM模型将用于Mark V系统
