IS200BICMH1A 连接器包括两个背板连接器

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200BICMH1A是GE为Mark VI系列开发的GE印刷电路板。Mark VI是通用电气Speedtronic系列的一部分，该系列自20世纪60年代末以来一直用于管理各种尺寸和复杂程度的燃气和蒸汽轮机系统。

IS200BICMH1A有一个设计有两个窄开口的前面板。前面板上粘贴有单板ID号和GE标识。它还说明了适当的插槽插入板。如果插入不当的机架位置，IS200BICMH1A可能会损坏。面板设计用于访问用户TP测试点。这些位于面板上狭窄开口的后面，并与位于开口右侧的相应标签对齐。这些标签包括1A, 1B, 1C, VAB, VBC, VDCP, VMG, VDCN和ACOM旁边的第一个开口，和DA1至DA4, TRG1, TRG, ACOM旁边的第二个开口。tpp1到TP9排在第一个开口后面，TP14到TP16排在第二个开口后面。许多其他测试点位于电路板上的其他点。

IS200BICMH1A上的电路板连接器包括两个背板连接器(P1/P2，)和四个垂直公脚连接器。其中三个并排放置，并标记为POD1, POD2和POD3。最后一个连接器位于直接后面的前面板。这是一个十针连接器。

IS200BICMH1A有150多个电容器，300个电阻和100个集成电路。该电路板由单个金属氧化物压敏电阻和五个电阻网络阵列组成。电路板上的代码是6BA02。

IS200BICMH1A 连接器包括两个背板连接器

The IS200BICMH1A is a GE printed circuit board developed by GE for the Mark VI series. The Mark VI is part of the GE Speedtronic family, which has been used since the late 1960s to manage gas and steam turbine systems of all sizes and levels of complexity.

The IS200BICMH1A has a front panel designed with two narrow openings. A board ID and GE label are affixed to the front panel. It also describes the proper slot to insert the board. The IS200BICMH1A may be damaged if inserted into the wrong rack position. The panel is designed to access user TP test points. These are located behind the narrow opening on the panel and are aligned with the corresponding label located to the right of the opening. These labels include 1A, 1B, 1C, VAB, VBC, VDCP, VMG, VDCN and the first opening next to ACOM, and DA1 to DA4, TRG1, TRG, and the second opening next to ACOM. tpp1 through TP9 line up behind the first opening and TP14 through TP16 line up behind the second opening. Many other test points are located at other points on the board.

The board connectors on the IS200BICMH1A include two backplane connectors (P1/P2) and four vertical pin connectors. Three of them are placed side by side and labeled POD1, POD2, and POD3. The last connector is located directly behind the front panel. This is a ten-pin connector.

The IS200BICMH1A has more than 150 capacitors, 300 resistors and 100 integrated circuits. The circuit board consists of a single metal oxide varistor and five resistance network arrays. The code on the board is 6BA02.

IS200BICMH1A 连接器包括两个背板连接器
