IS200BICHH1A 创新系列配置了T -10和T - dc硬件和应用程序

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200BICHH1A是GE为Mark VI系统制造的组件，作为桥接接口和控制印刷电路板。Mark VI系统是通用电气在20世纪60年代与Mark I一起开发的成功Speedtronic系列的一部分。

IS200BICHH1A安装在创新系列板架上。创新系列配置了T -10和T - dc硬件和应用程序。这些机架具有LAN选项和布尔逻辑指令，无需额外配置即可提供允许的诊断功能。IS200BICHH1A采用一个狭窄的前面板，其底部三分之一处有一个插头连接器(标记为JM)，顶部三分之一处有一个显示器。该显示器允许审查led信号观察。板上有18个led。

IS200BICHH1A有两个背板连接器。这些标着P1和P2。它有29个TP测试点，40多个集成电路，两个保险丝。保险丝是可更换的250 V, 200 mA保险丝。

IS200BICHH1A接收来自FOSB板的多路相位故障，并将故障解复用。IS200BICHH1A将故障分为两类。这些是桥接故障和BICH板故障。

IS200BICHH1A在任何时候都应被视为静电敏感板。在任何类型的维护开始之前，应将电路板从通电设备上拆下。我们的仓库团队将使用防静电套筒在运输过程中保护零件。请阅读并遵守手册或数据表等出版物中列出的所有制造商安全程序。

IS200BICHH1A 创新系列配置了T -10和T - dc硬件和应用程序

The IS200BICHH1A is a component manufactured by GE for the Mark VI system as a bridge interface and control printed circuit board. The Mark VI system is part of the successful Speedtronic family that GE developed with the Mark I in the 1960s.

The IS200BICHH1A is installed on the innovative series rack. The Innovation series is configured with T-10 and T-dc hardware and applications. These racks have LAN options and Boolean logic instructions to provide allowed diagnostics without additional configuration. The IS200BICHH1A features a narrow front panel with a plug connector (labeled JM) in the bottom third and a display in the top third. The display allows review of led signal observation. There are 18 leds on the board.

The IS200BICHH1A has two backplane connectors. These are labeled P1 and P2. It has 29 TP test points, more than 40 integrated circuits, and two fuses. The fuse is a replaceable 250 V, 200 mA fuse.

The IS200BICHH1A receives multiple phase faults from the FOSB board and demultiplexes the faults. IS200BICHH1A classifies faults into two categories. These are bridge failures and BICH board failures.

The IS200BICHH1A shall at all times be treated as an electrostatic sensitive board. Before any type of maintenance begins, the circuit board should be removed from the powered device. Our warehouse team will use anti-static sleeves to protect parts during transport. Read and follow all manufacturer safety procedures listed in publications such as manuals or data sheets.

IS200BICHH1A 创新系列配置了T -10和T - dc硬件和应用程序
