IS200BAIAH1BDC  可以接收来自终端板的信号

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200BAIAH1BDC是GE桥接应用接口板。

IS200BAIAH1BDC是一个替换PCB。该板可以接收来自终端板的信号，将其隔离，并提供接地参考。它还可以将数字输入转换为DSPX PCB上的模拟输出。它还有一个RS-232C I/O接口，从DSPX板和驱动器的键盘和PC连接。

IS200BAIAH1BDC可垂直滑入控制机架。将这张卡插入机架上正确的插槽是非常重要的。如果不这样做，将导致电路板损坏。在板的面板上，它表示只能将此板滑动到槽1。有一个LED指示灯正下方的顶部弹出标签。面板上总共有两个顶针和两个安装螺钉。安装单板时，建议将螺钉均匀拧紧，确保单板插入卡槽位。

IS200BAIAH1BDC由许多不同的组件组成。它有一个带有出厂安装固件的板载EEPROM。它还有3个继电器，50多个集成电路，6个晶体管，6个二极管，一个电感器，两个变压器，5个跳线和一个JTAG连接器。这块电路板上还有一百多个电阻器和电容器。有两个连接端口可插入控制机架上的卡槽。

有关IS200BAIAH1BDC的安装和组成的更多信息，请参阅GE数据表GEI-100268A。

IS200BAIAH1BDC  可以接收来自终端板的信号

IS200BAIAH1BDC is a GE bridging application interface board.

IS200BAIAH1BDC is a replacement PCB. The board can receive the signal from the terminal board, isolate it, and provide a grounding reference. It can also convert digital inputs to analog outputs on DSPX PCBS. It also has an RS-232C I/O interface that connects from the DSPX board and drive to the keyboard and PC.

The IS200BAIAH1BDC slides vertically into the control frame. It is very important to insert this card into the correct slot on the rack. Failure to do so will cause damage to the circuit board. On the panel of the board, it indicates that you can only slide this board into slot 1. There is an LED indicator right below the top of the pop-up TAB. There are a total of two thimbles and two mounting screws on the panel. When installing the board, you are advised to tighten the screws evenly to ensure that the board is inserted into the card slot.

The IS200BAIAH1BDC consists of a number of different components. It has an onboard EEPROM with factory installed firmware. It also has three relays, more than 50 integrated circuits, six transistors, six diodes, an inductor, two transformers, five jumpers, and a JTAG connector. There are also more than a hundred resistors and capacitors on this circuit board. There are two connection ports that can be inserted into the card slots on the control rack.

For more information about the installation and composition of the IS200BAIAH1BDC, see GE Data Sheet GEI-100268A.

IS200BAIAH1BDC  可以接收来自终端板的信号
