IS200AEPAH1AFD 安装在马克六涡轮控制系统
【产品详情】
1)备件
2)保修期:12个月!
3)包装:原包装与纸箱。
4)交货时间:付款后3天内发货
5)所有货物将在发货前进行测试。
制造具有连接可选辅助板的能力,IS200AEPAH1AFD板被简单地标记为印刷电路板。如果您决定使用可选的辅助板,它将通过两针连接器与AEPA板通信。辅助板与AEPA板通信用的两个引脚连接器为公引脚连接器,位于板的左上角。该板的其他一些组件是两个三插头连接器,六个金属氧化物压敏电阻(MOVs),以及许多其他组件。这个板上的移动点排列在一起,位于右上角,颜色为红色。
当IS200AEPAH1AFD板已安装在马克六涡轮控制系统,它将位于VME机架,VME机架将有21或13个插槽。该单板只占用一个VME槽位。AEPA板可以使用多种冗余模型,如单冗余、双冗余或三重冗余,根据您决定在什么上运行模型,该板实际上可以同时使用几种冗余类型。
IS200AEPAH1AFD模型可以使用两种不同类型的通信,即IONet或单元数据高速公路(UDH)。UDH是一个基于以太网的局域网,不仅可以与Mark VI系统中的其他电路板通信,还可以与Fanuc系列基于plc的控制器通信,这些控制器也是由通用电气制造的,以及EX2000发电机励磁控制。其他可以使用的系统可以在GER-4193A涡轮控制系统指令指南中找到。
IS200AEPAH1AFD 安装在马克六涡轮控制系统
Manufactured with the ability to connect optional auxiliary boards, the IS200AEPAH1AFD board is simply labeled as a printed circuit board. If you decide to use the optional auxiliary board, it will communicate with the AEPA board via a two-pin connector. The two pin connectors for the auxiliary board to communicate with the AEPA board are male pin connectors, located in the upper left corner of the board. Some of the other components of the board are two three-plug connectors, six metal oxide varistors (MOVs), and many others. The moving points on this board are arranged together, located in the upper right corner, and are colored red.
When the IS200AEPAH1AFD board has been installed in the Mark VI turbo control system, it will be located in the VME rack, which will have 21 or 13 slots. The board occupies only one VME slot. An AEPA board can use multiple redundancy models, such as single redundancy, double redundancy, or triple redundancy, and depending on what you decide to run the model on, the board can actually use several redundancy types at the same time.
The IS200AEPAH1AFD model can use two different types of communication, namely IONet or Unit Data Highway (UDH). The UDH is an Ethernet-based local area network that can communicate not only with other circuit boards in the Mark VI system, but also with the Fanuc family of PLC-based controllers, which are also manufactured by GE, as well as the EX2000 generator excitation control. Other systems that can be used can be found in the GER-4193A Turbine Control System Instruction Guide.
IS200AEPAH1AFD 安装在马克六涡轮控制系统
