IS200AEBMG1AFB 大致矩形板表面组成

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200AEBMG1AFB电路板是通用电气Speedtronic Mark VI涡轮控制系统的一部分。这种分布式控制系统由通用电气销售，作为控制和管理水力，蒸汽和燃气工业涡轮系统的完整解决方案。

IS200AEBMG1AFB由一个已经安装到载体框架上的大致矩形板表面组成。这个框架，标记1151x122OBQ01，允许板更容易地安装在机架系统内。该板不包括一个典型的马克六前面板安装硬件，以锁定它到位。这个安装框架延伸超出板的表面上的任何一个长边与多个螺钉安装。在板上也有切口，允许进入工厂在载体框架表面钻孔。其中几个是用来确保使用夹子和螺钉的载体板。

IS200AEBMG1AFB板本身标有参考名称，板的id号，GE标志，以及94V0和E99006等几个识别代码。该板也标记沿其边缘与+和-标志和“交流”。这些对应于上述螺丝安装在载体框架。

安装在IS200AEBMG1AFB上的组件包括6个垂直插头连接器、4个晶体管、40多个二极管、40多个使用金属薄膜等各种材料的电阻器和12个电容器。有关电路板组件及其使用的其他信息可以使用GE手册或数据表找到。

IS200AEBMG1AFB 大致矩形板表面组成

The IS200AEBMG1AFB board is part of the General Electric Speedtronic Mark VI turbine control system. This distributed control system is marketed by General Electric as a complete solution for controlling and managing turbine systems for the hydro, steam and gas industries.

The IS200AEBMG1AFB consists of a roughly rectangular plate surface that has been mounted to the carrier frame. This frame, labeled 1151x122OBQ01, allows the board to be more easily mounted within the rack system. The board does not include a typical Mark VI front panel mounting hardware to lock it in place. This mounting frame extends beyond the surface of the board on any one of the long sides with multiple screws mounted. There are also notches in the plate that allow access to the plant to drill holes in the surface of the carrier frame. Several of them are used to ensure the use of clamps and screws on the carrier plate.

The IS200AEBMG1AFB board itself is marked with a reference name, board id number, GE logo, and several identification codes such as 94V0 and E99006. The board is also marked along its edges with + and - signs and "communication". These correspond to the above screws installed in the carrier frame.

The components installed on the IS200AEBMG1AFB include six vertical plug connectors, four transistors, more than 40 diodes, more than 40 resistors using various materials such as metal films, and 12 capacitors. Additional information about board components and their use can be found using GE manuals or data sheets.

IS200AEBMG1AFB 大致矩形板表面组成
