IS200AEAAH1A 提供三重模块化冗余控制

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

IS200AEAAH1A是由通用电气制造和设计的，作为其Speedtronic系列的一部分。该电路板是Mark VI系列的一部分，这是后来的Speedtronic系统之一，提供三重模块化冗余控制，基于windows的操作系统预装了专有软件，如simplicity和GE控制系统工具箱。

IS200AEAAH1A设计有大量的表面安装元件。电路板表面有多个连接器，包括三个相互平行放置的端子带。这些条带中的每一条都有12个独立的连接器。该板还具有16插接连接器，一个三针雄性垂直插头和一个两个位置垂直母插头。另外，有一个直角连接器沿着一个短边。

其他组件包括8个继电器，每组4个。旁边是两个散热器和三个线绕电阻。该板还使用金属膜电阻器和其他电阻器，电容器和二极管，以及40多个集成电路。为了便于识别，大多数组件都用参考标志进行了标记。电路板上标有其板识别号和代码6BA00。

有关IS200AEAAH1A或Mark VI系列的更多信息，请参阅原始设备制造商发布的数据表，用户指南或手册。

IS200AEAAH1A 提供三重模块化冗余控制

The IS200AEAAH1A is manufactured and designed by General Electric as part of its Speedtronic family. The board is part of the Mark VI series, one of the later Speedtronic systems, offering triple modular redundancy control in a Windows-based operating system pre-installed with proprietary software such as simplicity and GE Control System Toolbox.

The IS200AEAAH1A is designed with a large number of surface mount components. There are multiple connectors on the board surface, including three terminal strips that are placed parallel to each other. Each of these strips has 12 separate connectors. The board also features 16 plug connectors, a three-pin male vertical plug and a two-position female vertical plug. In addition, there is a right Angle connector along a short side.

Other components include eight relays, four in each group. Next to it are two radiators and three wire-wound resistors. The board also uses metal film resistors and other resistors, capacitors and diodes, and more than 40 integrated circuits. For easy identification, most components are marked with reference marks. The board is marked with its board identification number and code 6BA00.

For more information about the IS200AEAAH1A or Mark VI series, please refer to the data sheets, user guides or manuals published by the original equipment manufacturer.

IS200AEAAH1A 提供三重模块化冗余控制
