369-HI-R-M-0-0-0 保护系统功能
【产品详情】
1）备件
2）保修期：12个月！
3）包装：原包装与纸箱。
4）交货时间：付款后3天内发货
5）所有货物将在发货前进行测试。
这种集成保护和控制系统是通用电气Multilin 369系列的一部分，适用于中型交流电机。通过使用波形捕获、事件报告、数据记录和内置可选计量功能(包括在此型号中)，369-HI-R-M-0-0-0能够降低维护成本并减少故障排除所花费的时间。继电器产生的数据可以很容易地在继电器的40个字符液晶显示器上或在运行通用电气EnerVista 369软件程序的计算机上进行查看。EnerVista还可以对这些数据进行趋势分析，以便进行更有效的分析。
369-HI-R-M-0-0-0的保护系统功能，如短路跳闸，能够通过检测过量幅度和产生适当的响应来限制对电机部件的损坏。如果震级超过相位CT初级x拾取电平一段指定的时间，则会发生跳闸。时间可以以10毫秒的增量进行调整，并通过继电器的设定值系统进行配置。如果短路时间延迟过于敏感，则可能在电机启动期间发生意外跳闸，用户可以使用系统生成的数据微调这些设置，以找到合适的折衷方案。
369-HI-R-M-0-0-0高约11.5英寸，宽8.5英寸，深5.5英寸。继电器的安装切口可以稍微小一点(11 " H, 7 " W)，因为继电器的尺寸朝后减小，前面板是设备的最大部分。
369-HI-R-M-0-0-0 保护系统功能
This integrated protection and control system is part of the General Electric Multilin 369 series for mid-sized AC motors. By using waveform capture, event reporting, data logging, and built-in optional metering features (included in this model), the 369-HI-R-M-0-0-0 reduces maintenance costs and reduces the time spent troubleshooting. The data generated by the relay can be easily viewed on the relay's 40-character LCD display or on a computer running the GE EnerVista 369 software program. EnerVista can also trend this data for more effective analysis.
The 369-HI-R-M-0-0-0 protection system features, such as short-circuit tripping, are able to limit damage to motor components by detecting excess amplitude and generating an appropriate response. If the magnitude exceeds the phase CT primary x pick level for a specified period of time, tripping occurs. The time can be adjusted in 10-millisecond increments and configured through the relay's setpoint system. If the short circuit time delay is too sensitive, an unexpected trip can occur during motor startup, and users can use the data generated by the system to fine-tune these Settings to find a suitable compromise.
369-HI-R-M-0-0-0 is approximately 11.5 inches high, 8.5 inches wide, and 5.5 inches deep. The mounting notch for the relay can be slightly smaller (11 "H, 7" W) because the size of the relay is reduced towards the back and the front panel is the largest part of the device.
369-HI-R-M-0-0-0 保护系统功能
