DS200CPCAG1ABB GE 接触器引脚板
【产品详情】
1)备件
2)保修期:12个月!
3)包装:原包装与纸箱。
4)交货时间:付款后3天内发货
5)所有货物将在发货前进行测试。
产品描述
GE接触器引脚板DS200CPCAG1ABB具有一个12针连接器和两个2针连接器。它还具有四个端子块连接最多十二个信号线。GE接触器引射板DS200CPCAG1ABB还配有24VDC 15A插座电源继电器。
继电器内部有活动部件,因此在驱动器中安装电路板时需要仔细考虑。如果继电器与驱动柜内的金属结构或其他部件碰撞,则很容易损坏。继电器很高,从电路板表面伸出来,很容易被击中。当您将电路板滑入驱动柜时,请确保您对电路板和机柜内部有良好的看法。缓慢插入单板,并将其与机架上的螺钉对齐。用一只手将螺钉插入孔中,另一只手用螺丝刀拧紧螺钉。但是,不要把电路板固定得太紧,以免螺丝把电路板弄裂,从而损坏电路板。使用垫圈,如果他们提供或使用在有缺陷的板。
然后,打开端子座上的螺丝,将电线插入相应的端子。用一只手保持电线插入端子,另一只手拧紧端子螺钉。抓住连接器并将其插入相应的连接器。轻轻地将它们压入连接器,以确保它们完全就位。
DS200CPCAG1ABB GE 接触器引脚板
Product description
The GE contactor pin board DS200CPCAG1ABB has one 12-pin connector and two 2-pin connectors. It also has four terminal blocks connecting up to twelve signal lines. The GE contactor ejector plate DS200CPCAG1ABB is also equipped with a 24VDC 15A socket power relay.
There are moving parts inside the relay, so careful consideration is required when installing the circuit board in the driver. If the relay collides with the metal structure or other components in the drive cabinet, it is easily damaged. The relay is tall and protrudes from the surface of the circuit board, making it easy to get hit. When you slide the board into the drive cabinet, make sure you have a good view of the board and the inside of the cabinet. Slowly insert the board and align it with the screws on the rack. Insert the screw into the hole with one hand and tighten the screw with the other hand using a screwdriver. However, do not fix the board too tightly so that the screws will not crack the board and damage the board. Use washers if they are supplied or used on defective plates.
Then, unscrew the screw on the terminal block and insert the wire into the corresponding terminal. Hold the wire into the terminal with one hand and tighten the terminal screw with the other hand. Grab the connector and plug it into the appropriate connector. Gently press them into the connector to ensure they are fully in place.
DS200CPCAG1ABB GE 接触器引脚板
GE | SR469-P5-HI-A20-E | GE | CT11T7F10PN1 | GE | 350-017614-132D |
GE | HE700GEN200C | GE | PMC676RCTXV2.30116C1145CR11V2.x | GE | UR6AH |
GE | IC695PSA040K | GE | DS200DCFBG1BLC | GE | UR6AV |
GE | DS200ITXDG1ABA | GE | IC695CPU315 | GE | UR8AH |
GE | IC698ACC701 | GE | IS420UCSBH4A | GE | IS200AEPCH1BAA |
GE | IC200MDL740 | GE | VMIVME-7750 | GE | IS210AEBIH3BEC |
GE | IC200MDL640 | GE | VMIVME-7750-734001 | GE | IS210BPPBH2BMD |
GE | IC200ALG320 | GE | 350-027750-734001K | GE | WESDAC |
GE | IC670ALG310-JA | GE | VMIACC-5595-208 | GE | D20ME |
GE | IC670CHS002 | GE | 350-805595-208J | GE | IC695CRU320 |
GE | UR8NH | GE | RS-FS-9001 | GE | IS220UCSAH1A |
GE | URSHA | 362A1052P404 | GE | IS220UCSAH1AK | |
GE | IC694MDL940 | GE | VMICVMIVME-7740-850 | GE | IS220PAICH2A |
GE | IC695PNC001 | 350-007740-850L | GE | 336A4940CSP11 | |
GE | IC694PWR330 | GE | 04220FL11232A | GE | VMIVME-7750 |
GE | IC694CHS392 | GE | H201Ti | GE | VMIVME-7750-834 |
GE | IC694CHS392 | GE | IS220UCSAH1A | GE | 350-027750-834/D |
