IS210AEDBH4AGD  GE  桥接接口卡

【产品详情】

1）备件

2）保修期：12个月！

3）包装：原包装与纸箱。

4）交货时间：付款后3天内发货

5）所有货物将在发货前进行测试。

产品描述

IS210AEDBH4AGD是由GE制造的Mark VI系统的板组件。Mark VI系统用于管理燃气轮机和蒸汽轮机，并具有集成的HMI/操作员界面，允许用户使用特殊设计的软件(如GE的simplicity图形平台)访问系统数据。

IS210AEDBH4AGD为桥接接口卡。该组件的前表面有许多连接器，包括标有574 9771-1 1301的直角电缆连接器。有两个头连接器，有六个或四个位置，但每个有两个垂直引脚。该板有9个雄性垂直引脚连接器，范围从6引脚到10引脚。电路板也有四个插头，每个插头有三个位置。

IS210AEDBH4AGD在前表面和后表面都有组件。背面主要是电容器和电阻器，但也有二极管和晶体管。前表面还有电容器和电阻器，包括20个金属薄膜电阻器。它也有二极管和晶体管。前表面有四个来自Bicron的变压器。这些标记为B9178，是封装的开关模式/脉冲变压器，旨在满足BIL额定值的高可靠性要求。变压器的Hipot电平为5 KVAC，开关频率为10KHz至500khz。集成电路有超过175种，包括只读芯片、振荡芯片等。

IS210AEDBH4AGD在9个地点进行钻井。这块木板的表面有许多槽。这些槽在其长度上由集成电路或变压器填充。这块板上标有几个代码。有关该板及其组件的更多信息可通过制造商出版物找到。

IS210AEDBH4AGD  GE  桥接接口卡

Product description

The IS210AEDBH4AGD is a board component of the Mark VI system manufactured by GE. The Mark VI system is used to manage gas and steam turbines and features an integrated HMI/ operator interface that allows users to access system data using specially designed software such as GE's simplicity graphics platform.

The IS210AEDBH4AGD is a bridge interface card. The front surface of the assembly has a number of connectors, including a right Angle cable connector marked 574 9771-1 1301. There are two head connectors that have six or four positions, but each has two vertical pins. The board has 9 male vertical pin connectors ranging from 6 pins to 10 pins. The board also has four plugs, each with three positions.

The IS210AEDBH4AGD has components on both the front and rear surfaces. The back is mostly capacitors and resistors, but there are also diodes and transistors. The front surface also has capacitors and resistors, including 20 metal film resistors. It also has diodes and transistors. There are four Bicron transformers on the front surface. Labeled B9178, these are packaged switching mode/pulse transformers designed to meet the high reliability requirements of the BIL rating. The Hipot level of the transformer is 5 KVAC and the switching frequency is 10KHz to 500 KHZ. There are more than 175 types of integrated circuits, including read-only chips, oscillating chips, etc.

The IS210AEDBH4AGD drilled Wells at nine locations. The surface of the board has many grooves. These slots are filled along their length by integrated circuits or transformers. This board is marked with several codes. More information about the board and its components can be found through manufacturer publications.

IS210AEDBH4AGD  GE  桥接接口卡
