IS200TTURH1CFD GE 单板类型终端板
【产品详情】
1)备件
2)保修期:12个月!
3)包装:原包装与纸箱。
4)交货时间:付款后3天内发货
5)所有货物将在发货前进行测试。
IS200TTURH1CFD技术规范
单板类型终端板
功能缩写/缩写ttur
制造商通用电气工业系统
脉冲速率I/O量4
系列mark VI IS200
同步方法单相PTs
终端板型屏障
产品描述
IS200TTURH1CFD型号由通用电气作为VTUR终端屏障板销售,在操作时使用四种不同的输入和输出(I/O)类型。这些I/O类型如下:
两个支持向量机I/ o
4个脉冲速率或速度I/ o
两个分
同步继电器
上述所有I/ o也都有各自独特的特性。相对于脉冲速率(速度)I/ o,它们通常被称为磁速度传感器,工作在2到14000赫兹。Mark VI系统中的模型有几个特定于应用程序的I/O,该模型与同步I/O一起使用。同步方式包括备份同步保护、自动同步和手动同步三种。
如上所述,IS200TTURH1CFD模型有两个PT输入,这两个输入都是单相输入,具有重要的功能。PT输入用于通过VTUR卡监控线路总线和发电机。通过TTUR模型匹配所选涡轮机的速度,在通过TTUR命令关闭断路器之前,需要匹配线路电压和发电机。
IS200TTURH1CFD型号还有一个内部同步检查继电器,标记为K25A,如果使用该功能,则必须在备份保护模块上执行潜在转差计算和备份阶段,或通过外部备份同步检查继电器。备用保护模块也可以与TTUR板使用的主控模块一起使用。
IS200TTURH1CFD GE 单板类型终端板
IS200TTURH1CFD technical specification
Board Type Terminal board
Function abbreviation/abbreviation ttur
Manufacturer General Electric Industrial Systems
Pulse rate I/O quantity 4
Series mark VI IS200
Synchronous method single-phase PTs
Terminal plate type barrier
Product description
The IS200TTURH1CFD model, marketed by General Electric as a VTUR terminal barrier board, uses four different input and output (I/O) types when operating. These I/O types are as follows:
Two support vector machines I/ o
4 pulse rates or speed I/ o
Two points
Synchronous relay
All of the above I/ OS also have their own unique characteristics. In contrast to the pulse rate (speed)I/ o, they are often referred to as magnetic velocity sensors and operate at 2 to 14,000 Hertz. The model in the Mark VI system has several application-specific I/ OS, which are used in conjunction with synchronous I/O. Synchronization modes include backup synchronization protection, automatic synchronization, and manual synchronization.
As mentioned above, the IS200TTURH1CFD model has two PT inputs, both of which are single-phase inputs and have important functions. The PT input is used to monitor the line bus and generator through the VTUR card. The speed of the selected turbine is matched through the TTUR model, and the line voltage and generator need to be matched before the circuit breaker is turned off through the TTUR command.
The IS200TTURH1CFD model also has an internal sync check relay, labeled K25A, and if this feature is used, the potential slip calculation and backup phase must be performed on the backup protection module or through an external backup sync check relay. The standby protection module can also be used with the main control module used on the TTUR board.
IS200TTURH1CFD GE 单板类型终端板
