IS215UCVEM10A GE 控制器模块

IS215UCVEM10A GE  控制器模块

IS215UCVEM10A GE  控制器模块

制造商ge工业系统

内存32mb DRAM, 16MB紧凑型闪存模块，128KB二级缓存，电池支持的SRAM

微处理器英特尔赛扬300MHz

操作系统qnx

系列speedtronic Mark VI涡轮控制

部件编号is215ucvem01a

产品类型ucvem01控制器

说明书geh - 6421c卷二

IS215UCVEM01A是Mark VI Speedtronic系列中的UCVE控制器模块。这是通用电气最复杂的涡轮控制系统之一中使用的双面控制器。MKVI可用于单工和三模冗余应用。因为有这么多的控制器板是如此相似，我们建议订购一个精确的副本的板，你目前正在使用，以确保兼容性。

IS215UCVEM01A有一个附加的前面板。这包括放置在顶部固定螺钉下的三个led。led是状态指示灯，旨在帮助用户了解模块运行时发生的情况。面板还包括一个mezz卡插槽、一个复位按钮、两个以太网端口、一个鼠标或键盘端口以及用于LAN和SVGA的端口。固定螺钉放置在顶部和底部。这些将在安装后将模块锁定到位。当需要将模块从机架上拉下来时，它们还充当手柄。

IS215UCVEM10A GE  控制器模块

Manufacturer GE Industrial Systems

Memory 32MB DRAM, 16MB Compact Flash Module, 128KB L2 Cache, Battery Backed SRAM

Microprocessor Intel Celeron 300MHz

Operating System QNX

Series Speedtronic Mark VI Turbine Control

Part Number IS215UCVEM01A

Product Type UCVEM01 Controller

Instruction Manual GEH-6421C Volume II

The IS215UCVEM01A is an UCVE controller module within the Mark VI Speedtronic series.  This is a dual-sided controller used within one of GE’s most complex turbine control systems.  The MKVI can be used for both simplex and triple modular redundant applications.  Because there are so many controller boards available that are so similar, we recommend ordering an exact duplicate of the board you are currently using to ensure compatibility.

The IS215UCVEM01A has an attached front faceplate.  This includes three LEDs placed just under the top set screw.  The LEDs are status indicators designed to help users understand what is going on with the module as it runs.  The faceplate also includes a mezzanine card slot, a reset button, two Ethernet ports, a port for a mouse or keyboard, and ports for LAN and SVGA.   Set screws are placed at the very top and bottom.  These will lock the module in place after installation.  They also act as handles any time the module needs to be pulled from the rack.
