IS215UCVEH2AB GE 标准标志VI控制器

IS215UCVEH2AB GE  标准标志VI控制器

IS215UCVEH2AB GE  标准标志VI控制器

单板计算机IS215UCVEH2AB用于帮助操作涡轮应用代码。它将通过可用的VME总线与I/O板通信。UCVE控制器可用于陆海航空衍生产品，工厂平衡或蒸汽和气体产品。

背板要求是的，根据GEH-6421C卷二马克六涡轮控制手册

以太网端口数量1,RJ45

组变异ucveh2

内存类型32mb DRAM和16mb Flash

微处理器300兆赫英特尔赛扬

型号类型标准标志VI控制器

监控接口svga

操作系统qnx

电源要求+ 5vdc, 6A典型，最大8A

IS215UCVEH2AB模型被标记为标准标志VI控制器，设计为6U高，单/双槽，单板计算机，通常用于操作涡轮机应用程序代码。该型号的位置在VME机架上，有21个或13个插槽。当位于控制模块时，它将通过VME总线与其他涡轮I/O板通信。该板使用的典型操作系统是QNX。QNX系统是一个多任务、实时操作系统，专为高可靠性和高速工业应用而设计。

IS215UCVEH2AB GE  标准标志VI控制器

Single Board Computer IS215UCVEH2AB is used to help operate turbine application codes.   It will communicate with I/O boards through the available VME bus.   The UCVE controller can be used with Land-Marine aero-derivative, Balance of Plant, or steam and gas products.

Backplane Requirement Yes, according to GEH-6421C Vol. II Mark VI Turbine Control Manual

Ethernet Port Quantity 1, RJ45

Group Variation UCVEH2

Memory Types 32 Mb of DRAM and 16 Mb of Flash

Microprocessor 300 MHz Intel Celeron

Model Type Standard Mark VI Controller

Monitor Port SVGA

Operating System QNX

Power Requirements +5 VDC, 6A Typical, Max 8A

Labeled as a Standard Mark VI Controller the IS215UCVEH2AB model was designed as 6U high, single/double slot, single board computer that is typically used for operating the turbine application code.  The location of this model is in a VME rack with twenty-one or thirteen slots.  When located in the control module it will communicate with the other turbine I/O boards through the VME bus.  The typical operating system that is used with this board is QNX.  The QNX system is a multi-tasking, real-time OS system which is designed for highly reliable and high-speed industrial applications.

IS215UCVEH2AB GE  标准标志VI控制器
