IS215ACLEH1BB GE 励磁控制器

IS215ACLEH1BB GE  励磁控制器

IS215ACLEH1BB GE  励磁控制器

型号IS215ACLEH1BB

功能缩写/缩写

ex2100系列励磁控制器

分组和功能修订h1b

潜在添加元件prom

硬件功能led, CPU和PCI控制器

基本输入/输出系统

Cache level level 2, 128kb

体重1磅4盎司

运输尺寸18x12x12英寸

原产国美国(美国)

IS215ACLEH1BB型号是EX2100e系列的一部分，作为应用控制层模块，通常是基于微处理器的控制器。该板的主要用途是在ISBus和以太网等通信网络上执行几种不同的任务。当板已安装，它将占据两个半槽在EX2100励磁板机架或创新系列驱动器。ACLE板也将位于控制柜内。有许多不同的软件功能，包括但不限于以下内容:

I/O点和内部布尔值强制

应用控制创新系列驱动器

非易失性闪存

在线应用程序配置加载

控制块

IS215ACLEH1BB单板采用以太网连接，使用板上BIOS功能初始化的irq5。ACL板的以太网接口为10baseT或RJ45插孔，位于ACL板的前面板上。作为一个基于微处理器的控制，该板有一个外围组件互连(PCI)控制器，该控制器将管理不同的输入和输出，配置传输到PCI总线以及管理各种存储功能。

IS215ACLEH1BB模型还具有128 KB L2缓存，该缓存与PCI控制器一起使用并由其控制，该缓存设置在152 NC缓存线上，该缓存将填充L1和L2缓存之间的线路。ACLE板的另一个特点是一个闪存设备，这个存储设备位于目标接口的本地总线侧，被称为device 1，该设备只能以字节模式访问。

IS215ACLEH1BB GE  励磁控制器

Model IS215ACLEH1BB

Function abbreviations/abbreviations

ex2100 series excitation controller

Grouping and function revision h1b

Potentially add component prom

Hardware features led, CPU and PCI controller

Basic input/output system

Cache level level 2, 128kb

Weighs 1 pound, 4 ounces

Shipping size 18x12x12 inches

Country of Origin USA (USA)

The IS215ACLEH1BB model is part of the EX2100e family as an application control layer module, usually a microprocessor-based controller. The main purpose of the board is to perform several different tasks on communication networks such as ISBus and Ethernet. When the board has been installed, it will occupy two half slots in the EX2100 exciter board frame or Innovation series drive. ACLE board will also be located in the control cabinet. There are many different software features, including but not limited to the following:

I/O points and internal Booleans are enforced

Application control Innovation series drives

Non-volatile flash memory

Online application configuration loading

Control block

The IS215ACLEH1BB board connects to the Ethernet and uses the irq5 initialized by the BIOS function on the board. The Ethernet port on the ACL board is a 10baseT or RJ45 jack on the front panel of the ACL board. As a microprocessor-based control, the board has a Peripheral Component Interconnect (PCI) controller that will manage different inputs and outputs, configure transfers to the PCI bus, and manage various storage functions.

The IS215ACLEH1BB model also has a 128 KB L2 cache that is used with and controlled by the PCI controller, which is set on a 152 NC cache line that will fill the line between the L1 and L2 caches. Another feature of the ACLE board is a flash memory device located on the local bus side of the target interface, called device 1, which can only be accessed in byte mode.
