IS200WNPSH1ABA GE 驱动系统

IS200WNPSH1ABA GE  驱动系统

IS200WNPSH1ABA GE  驱动系统

制造商通用电气驱动系统

体重1lbs

系列mark VI涡轮控制系统

部件编号为IS200WNPSH1ABA

产品类型标志VI子板

IS200WNPSH1ABA是由GE工业驱动系统制造的PCB。IS200WNPSH1ABA在应用程序中充当子板，具有两个连接器端口，可以连接电缆。

IS200WNPSH1ABA是一个矩形板，两个表面都有组件。底面有一个背板连接器(P1)，有48个公脚。后表面也标记RA/00。前表面有两个母插头连接器，标记为JE1和JE2。这些并排放置在电路板的右侧。

IS200WNPSH1ABA的前表面有一个单金属氧化物压敏电阻。压敏电阻元件随外加电压改变其电阻。电路板上还有16个熔断器(TR1和TR16)，它们位于电路板上的两行，每行8个。单板底部有三行光器件，分别标识为D2、B2、Z2。

IS200WNPSH1ABA具有以下组成部分:

附在主板左侧的散热器组件。

几行二极管

多个电容器和电阻。

在电路板的左上角有一个标记为“DN1”的单一组件。这是一个单相直流整流桥。

请与GE联系获取手册、数据表和其他文档。

IS200WNPSH1ABA GE  驱动系统

Manufacturer General Electric Drive Systems

Weight 1lbs

Series mark VI turbine control system

The part number is IS200WNPSH1ABA

Product type label VI subboard

The IS200WNPSH1ABA is a PCB manufactured by GE Industrial Drive Systems. The IS200WNPSH1ABA acts as a daughter board in the application, with two connector ports that allow cables to be connected.

The IS200WNPSH1ABA is a rectangular plate with components on both surfaces. There is a backplane connector (P1) on the underside with 48 male pins. The rear surface is also marked RA/00. The front surface has two female plug connectors, labeled JE1 and JE2. These are placed side by side on the right side of the board.

The IS200WNPSH1ABA has a single metal oxide varistor on the front surface. A varistor element changes its resistance with applied voltage. There are also 16 fuses (TR1 and TR16) on the board, which are located in two rows of eight on each row on the board. There are three rows of optical components at the bottom of the board, identified as D2, B2, and Z2.

IS200WNPSH1ABA has the following components:

Radiator assembly attached to the left side of the motherboard.

Row diode

Multiple capacitors and resistors.

In the top left corner of the board is a single component labeled "DN1". This is a single phase DC rectifier bridge.

Contact GE for manuals, data sheets, and other documents.
