IS200STCIH6AED由许多不同类型的组件组成。在电路板的右下角和左下角，有两个工厂钻孔的端子孔，并已加固。还有两个大的钻孔在左边和右边，是略高于中心的板边缘。单板底部有两个绿色的端子带，并有数字标识。底部条形标签为2-52，均匀编号。顶部端子带的奇怪编号为1-51。在板的顶部边缘，有一个37针RS-232母端口。电路板的零件号在卡片的右下方。该板也有一个3针插孔连接，是白色的，位于顶部端子带上方一点。这张卡还有91个电阻、24个电容、27个二极管、2个晶体管和23个集成电路。

由于IS200STCIH6AED是PCB，因此应始终小心处理。为了防止静电的积聚和释放造成任何类型的损坏，在准备安装之前，必须将单板放在防静电包装中。一旦可以安装，一定要戴上防静电腕带。此外，为了帮助安装过程，最好记录下新板正在更换的原板上的电线和电缆的位置。

IS200STCIH6AED GE 传输模块

The IS200STCIH6AED is made up of many different types of components. On the bottom right and left corners on the board, there are two factory drilled terminal holes that have been reinforced. There are also two large drilled holes on the left and right sides that are a little above the center of the board edges. There are two green terminal strips on the bottom of the board that has been numerically labeled. The bottom strip is labeled 2-52 and are evenly numbered. The top terminal strip is oddly numbered 1-51. On the top edge of the board, there is a 37-pin RS-232 female port. The board’s part number is on the bottom right side of the card. The board also has a 3-pin jack connection that is white and located a little above the top terminal strip. This card also has 91 resistors, 24 capacitors, 27 diodes, 2 transistors, and 23 integrated circuits.

Because the IS200STCIH6AED is a PCB, it should always be handled with care. To prevent any type of damage due to a buildup and release of static electricity, it is imperative that the board be kept in antistatic packaging until it is ready to be installed. Once it can be installed be sure to wear an antistatic wristband. Also, to help with the installation process, it is advisable to make a note of the positions of the wires and cables from the original board the new board is replacing.
