IS200EPSMG1AED TSVO伺服阀终端
IS200EPSMG1AED是几个TSVO伺服阀终端板之一，最初由通用电气公司为其GE Mark VI汽轮机控制系统创建和销售。在大多数Speedtronic应用中，这种伺服终端板通常连接到三线圈伺服致动粥
IS200EPSMG1AED伺服阀板设计为使用低电平信号。这些信号可能包括0至+/-50 V直流模拟信号、交流信号(额定电压低于24 VAC)或4至20 mA电流回路信号
这块板重约2.00磅
S200EPSMG1AED沿两个长边都有缺口。一条长边在拐角处有凹口，而另一条沿其长度方向有较小的等距凹口。这块板是工厂在三个角上钻孔的。安装在电路板表面的元件带有参考标记，也可能有其原始制造商零件号:这些可以引导您查阅数据手册，了解更多信
IS200EPSMG1AED由六个d形外壳连接器、两个端子板和几个垂直插头组成。它还有四个变压器、晶体管、继电器、集成电路、电阻器和电容器。最后，电路板有六个跳线开关。每个跳线有六种可能的设置。
IS200EPSMG1AED TSVO伺服阀终端
The IS200EPSMG1AED is one of several TSVO servo valve terminal boards originally created and marketed by General Electric for its GE Mark VI steam turbine control system. In most Speedtronic applications, this servo terminal board is usually connected to a three-coil servo-actuated porridge
The IS200EPSMG1AED servo valve plate is designed to use low level signals. These signals may include 0 to +/-50 V DC analog signals, AC signals (rated below 24 VAC), or 4 to 20 mA current loop signals
The board weighs about 2.00 pounds
The S200EPSMG1AED has notches along both long sides. One long side has a notch at the corner, while the other has a smaller equidistant notch along its length. The board was drilled at three corners by the factory. Components mounted on the surface of the board carry reference marks and may also have their original manufacturer part number: these can direct you to the data book for more information
The IS200EPSMG1AED consists of six D-housing connectors, two terminal boards, and several vertical plugs. It also has four transformers, transistors, relays, integrated circuits, resistors and capacitors. Finally, the board has six jumper switches. There are six possible Settings for each jumper.
