GE IS200TSVCH2AED MRP246517 控制器模块

GE IS200TSVCH2AED MRP246517  控制器模块

GE IS200TSVCH2AED MRP246517  控制器模块

is 200 Vtc CCH 1C是GE公司制造的电路板组件，是Mark V系统的一部分。MKV是燃气和蒸汽机管理Speedtronic系列的一部分，该系列始20世纪60年代的Mark 1，并通过Mark V和Mark Vle延续了几十年，Mark V有一个连接到操作员界面的中央控制模块，该操作员界面允许最终用户通过使用Windows平台PC构建的界面访问报警状态和系统数据

作为热电偶输入板，IS200VTCCH1C通过TBTC和DTTC端子板等端子板接受24路热电输入。IS20VTCCH1C仅支持T、S、K、J和E型热电偶它还支持范围为-8mV至+45mV的mV输入。该板不支持B、N或R型热电偶，或-20mV至-9mV或+46mV至+95mV的mV输入。如果需要这些范围，则需要一个VTCCH2板。

IS200VTCCH1C内置两个背板和四个其他板连接器。这些其他连接器由导电点或导电达线制成，这块板上的电容和电阻数以百计，这些都有编号并带有参考标记，它还具有二极管、电感线圈或磁珠以及TP测试点，它还具有许多集成电路，现场可编程门阵列Field Programmable GataArrav的缩写) 5、CMOS静态RAM和数字信号处理器。前面板上安装了三个ed组件，分别标记为运行(绿色LED、)故(红色LED)和状态(橙色LED)。)

GE IS200TSVCH2AED MRP246517  控制器模块

The is 200 Vtc CCH 1C is a circuit board component manufactured by GE as part of the Mark V system. The MKV is part of the Speedtronic family of gas and steam engine management that began with the Mark 1 in the 1960s and continued for decades through the Mark V and the Mark Vle, which had a central control module connected to the operator interface. The operator interface allows end users to access alarm status and system data through an interface built using a Windows platform PC

As a thermocouple input board, the IS200VTCCH1C accepts 24 thermoelectric inputs via terminal boards such as TBTC and DTTC terminal boards. The IS20VTCCH1C supports only T, S, K, J, and E thermocouples. It also supports mV inputs ranging from -8mV to +45mV. The board does not support type B, N, or R thermocouples, or mV inputs from -20mV to -9mV or +46mV to +95mV. If these ranges are required, a VTCCH2 board is required.

The IS200VTCCH1C has two built-in backplanes and four other board connectors. These other connectors are made of conductive points or wires, hundreds of capacitors and resistors on this board, which are numbered and marked with reference, it also has diodes, inductors or beads, and TP test points, it also has many integrated circuits, Field Programmable GataArrav) 5, CMOS static RAM and digital signal processor. Three ed components are installed on the front panel, labeled Run (green LED,) Off (red LED) and Status (orange LED).

GE IS200TSVCH2AED MRP246517  控制器模块
