>>>>>型号: IS220PTCCH1A REV：D 热电偶输入模块 管理和控制燃气
[产品说明]
品牌：GE
型号：IS220PTCCH1A REV：D
产品类型：热电偶输入模块
正常模式抑制：250mV
微处理器：AMD-K6 300 MHz
工作温度：-30 至 65 C
尺寸：8.26 cm 宽 x 4.19 cm
技术：表面贴装
维修：3-7 天
付款方式：电汇，西联
汇款 装运港：中国厦门
交货时间：1-3个工作日
条件：全新和 100% 原始
保修：12 个月
IS220PTCCH1A 提供 .25 华氏度的最大软件错误/一致性误差。共模电压为 +/- 5 V，交流共模抑制为 100dB @50/60Hz。共模抑制包括对硬件和软件的滤波。该装置还包括 250 mV RMS @ 50/60 Hz (+/-5%) 的正常模式抑制以及高/低硬件和软件限制检查。该装置设计用于在 -22 至 +149 华氏度的环境条件下运行。
该IS220PTCCH1A是通用电气制造的热电偶输入，用于Mark VI / MarkVIe系统。这些系统是通用电气后来开发和发布的一些 Speedtronic 系统，用于管理和控制燃气、水力和蒸汽工业涡轮机系统。该套件具有内部放置的BPPx处理器板以及用于热电偶输入功能的采集板。
该IS220PTCCH1A可用于单工、双工和三重模块化冗余应用。该板可支持 E、J、K、S 和 T 标准热电偶以及跨度为 -8 至 45 mV 的 mV 输入。 E、J、K、S 和 T 热电偶可以接地或不接地，并且可以位于距离涡轮机 I/O 面板 984 英尺的地方。电缆电阻必须保持在最大 450 Ω。使用的包数决定了以下内容：
数量 1 IS220PTCCH1A - 12 个热电偶输入
2 IS220PTCCH1A - 24 个热电偶输入数量
数量 3 IS220PTCCH1A - 用于 TMR 配置
IS220PTCCH1A 提供 .25 华氏度的最大软件错误/一致性误差。共模电压为 +/- 5 V，交流共模抑制为 100dB @50/60Hz。共模抑制包括对硬件和软件的滤波。该装置还包括 250 mV RMS @ 50/60 Hz (+/-5%) 的正常模式抑制以及高/低硬件和软件限制检查。该装置设计用于在 -22 至 +149 华氏度的环境条件下运行。
[其他型号推荐]
>>>>> Model: IS220PTCCH1A REV: D Thermocouple input module manages and controls gas
Brand: GE
Model: IS220PTCCH1A REV: D
Product Type: Thermocouple input module
Normal mode suppression: 250mV
Microprocessor: AMD-K6 300 MHz
Operating temperature: -30 to 65 C
Dimensions: 8.26cm wide x 4.19cm
Technology: Surface mount
Maintenance: 3-7 days
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
The IS220PTCCH1A provides a maximum software error/consistency error of.25 degrees Fahrenheit. The common-mode voltage is +/ -5 V, and the AC common-mode rejection is 100dB@50/60Hz. Common-mode suppression includes filtering of hardware and software. The unit also includes 250 mV RMS @ 50/60 Hz (+/-5%) normal mode suppression and high/low hardware and software limit checks. The unit is designed to operate in ambient conditions ranging from -22 to +149 degrees Fahrenheit.
The IS220PTCCH1A is a GE manufactured thermocouple input for MarkVI/MarkVIe systems. These systems are some of the Speedtronic systems later developed and released by GE to manage and control gas, hydraulic and steam industrial turbine systems. The kit features an internally placed BPPx processor board as well as a capture board for thermocouple input functions.
The IS220PTCCH1A can be used in simplex, duplex and triple modular redundancy applications. The board supports E, J, K, S and T standard thermocouples as well as mV inputs spanning -8 to 45 mV. E, J, K, S, and T thermocouples can be grounded or ungrounded and can be located up to 984 feet from the turbine I/O panel. Cable resistance must be maintained at a maximum of 450 Ω. The number of packets used determines the following:
Quantity 1 IS220PTCCH1A - 12 thermocouple inputs
2 IS220PTCCH1A-24 thermocouple input number
Quantity 3 IS220PTCCH1A - Used for TMR configuration
The IS220PTCCH1A provides a maximum software error/consistency error of.25 degrees Fahrenheit. The common-mode voltage is +/ -5 V, and the AC common-mode rejection is 100dB@50/60Hz. Common-mode suppression includes filtering of hardware and software. The unit also includes 250 mV RMS @ 50/60 Hz (+/-5%) normal mode suppression and high/low hardware and software limit checks. The unit is designed to operate in ambient conditions ranging from -22 to +149 degrees Fahrenheit.
