>>>>>型号:IS230PCAAH1A 燃气轮机控制模块 具有多种保护功能
[产品说明]
品牌：GE
型号：IS230PCAAH1A
产品类型：燃气轮机控制模块
尺寸：17.71×13.77×7.87厘米
工作温度：-30至65摄氏度
系列：Mark VIe
付款方式：电汇，西联
汇款 装运港：中国厦门
交货时间：1-3个工作日
条件：全新和 100% 原始
保修：12 个月
IS230PCAAH1A的主要功能和特点：
控制燃气轮机运行：该模块专为燃气轮机设计，用于控制燃气轮机的运行，并确保其安全、稳定地运行。
高可靠性和稳定性：采用先进的微处理器技术和数字信号处理技术，能够快速响应燃气轮机的各种变化和需求，实现精准控制。
多种保护功能：具有多种保护功能，可以防止燃气轮机在异常情况下发生故障或损坏。
友好的人机界面：方便进行操作和维护。
集成能力：可以与其他的控制系统进行集成，实现整体的控制和监测。
IS230PCAAH1A的功能描述：
该模块适用于单工、双工和 TMR 系统。单个TCAT终端板将信号输入分配到一个、两个或三个PCAA模块。
相邻的JGPA板的屏蔽接地和24 V现场电源端子补充了PCAA和TCAT上的端子。模块包括一个由所有 Mark VIe 分布式 I/O 板共享的处理器板、两个应用 I/O 板和一个终端板。
整个模块被视为最不可更换的单元，并且不提供任何帮助来诊断或更换组成模块的单个电路板。
该模块由一个 28 V 直流电源连接器和两个 RJ45 以太网连接器供电。在模块的边缘，120 个欧式盒式端子提供现场设备 I/O，通过连接器 P4 为 JGPA 板供电。该模块通过连接器 P1 和 P2 上的两根 68 针电缆连接到 TCAT。
PCAA信号分为两组。TCAT端子板将信号输入路由到单个、双通道或TMR PCAA模块。专用于单个PCAA模块的信号连接到端子。如果不需要扇形输入，则可以在没有 TCAT 的情况下使用 PCAA。
[其他型号推荐]
>>>>> Model :IS230PCAAH1A gas turbine control module with a variety of protection functions
Brand: GE
Model: IS230PCAAH1A
Product Type: Gas turbine control module
Size: 17.71×13.77×7.87 cm
Operating temperature: -30 to 65 degrees Celsius
Series: Mark VIe
Payment method: Wire transfer, Western Union
Port of shipment for remittance: Xiamen, China
Delivery time: 1-3 working days
Condition: New and 100% original
Warranty: 12 months
Main functions and features of IS230PCAAH1A:
Control gas Turbine operation: This module is designed for gas turbines to control the operation of gas turbines and ensure their safe and stable operation.
High reliability and stability: Using advanced microprocessor technology and digital signal processing technology, it can quickly respond to various changes and needs of gas turbines to achieve precise control.
Multiple protection features: Features a variety of protection features to prevent failure or damage to the gas turbine under abnormal conditions.
User-friendly interface: easy to operate and maintain.
Integration capability: It can be integrated with other control systems to achieve overall control and monitoring.
Function description of IS230PCAAH1A:
The module is suitable for simplex, duplex and TMR systems. A single TCAT terminal board distributes signal inputs to one, two, or three PCAA modules.
The shielded ground of the adjacent JGPA board and the 24 V field power terminals complement the terminals on the PCAA and TCAT. The module consists of a processor board shared by all Mark VIe distributed I/O boards, two application I/O boards, and a terminal board.
The entire module is considered the least replaceable unit, and no help is provided to diagnose or replace the individual circuit boards that make up the module.
The module is powered by a 28 V DC power connector and two RJ45 Ethernet connectors. At the edge of the module, 120 European box terminals provide field device I/O and power the JGPA board via connector P4. The module is connected to the TCAT via two 68-pin cables on connectors P1 and P2.
PCAA signals are divided into two groups. The TCAT terminal board routes the signal input to a single, two-channel, or TMR PCAA module. Signals dedicated to individual PCAA modules are connected to terminals. If sector input is not required, PCAA can be used without TCAT.
