DS200FCGDH1B 门分配和状态卡 接收到的信号转换为单元门控信号

☆型号：DS200FCGDH1B  门分配和状态卡   接收到的信号转换为单元门控信号

【产品详情】

制造商:GE通用电气

系列:mark V

部件号:DS200FCGDH1B

功能描述:lci控制和浇注保形涂层

功能缩写:fcgd

PCB涂层:保形涂层

功能修订版1:b

DS200FCGDH1B是一款门分配和状态卡，也被称为门控分配和状态卡（FCGD）。这款卡片由通用电气（GE）为其Mark V板系列开发，可以安装在许多GE品牌的驱动器中。一旦安装，它会充当六脉冲相位控制不可逆桥的接口系统。

DS200FCGDH1B的主要功能包括接收来自DSPC（数字信号处理卡）的信息，并将其中继到板进行解密。这样，它就可以生成有关诊断信息和系统反馈的信号。然后，这些反馈信号通过驱动器的集成VME背板发送。此外，该卡还从驱动器的集成DSPC收集大量数据，并将接收到的信号转换为单元门控信号。所有系统桥支路接收这个信元选通信号，并将多路复用的信元状态信息返回到该卡。反馈信号也由FCGD板接收和缩放，包括频率、电压和电路板状态信息。

DS200FCGDH1B还包括一个集成的IMOK LED状态指示灯，为用户提供基本的系统状态信息。在设备手册和数据表中，可以找到有关DS200FCGDH1B接线和安装的图解指南。此外，这款门分配和状态卡广泛应用于各种工业自动化和控制应用中，包括石油和天然气、电力工业、化工、水处理、制药和制造业等领域。

【英文介绍】

Manufacturer ：GE General Electric

Series： Mark V

Part Number ：DS200FCGDH1B

Functional Description： LCI Control & Gating Conformal Coat

Functional Acronym： FCGD

PCB Coating： Conformal Coating

Functional Revision 1： B

The DS200FCGDH1B is a gate assignment and status card, also known as the Gate Assignment and Status Card (FCGD). The card was developed by General Electric (GE) for its Mark V board line and can be installed in many GE branded drives. Once installed, it acts as an interface system for the six-pulse phase control irreversible bridge.

The main functions of the DS200FCGDH1B include receiving information from the DSPC (Digital Signal Processing Card) and passing it to the board for decryption. In this way, it can generate signals about diagnostic information and system feedback. These feedback signals are then sent through the drive's integrated VME backplane. In addition, the card collects a large amount of data from the drive's integrated DSPC and converts the received signal into a unit gated signal. All system bridge branches receive this cell select communication number and return multiplexed cell status information to the card. Feedback signals are also received and scaled by the FCGD board and include frequency, voltage, and board status information.

The DS200FCGDH1B also includes an integrated IMOK LED status indicator to provide users with basic system status information. An illustrated guide to wiring and installation of the DS200FCGDH1B can be found in the equipment manual and data sheets. In addition, this door assignment and status card is widely used in a variety of industrial automation and control applications, including oil and gas, power industry, chemical, water treatment, pharmaceutical and manufacturing industries.
