IC695CHS007LT
IC695CHS007LT

IC695CHS007LT 可编程自动化控制器 双连接器插槽

型号:IC695CHS007LT可编程自动化控制器双连接器插槽【产品详情】IC695CHS007是PACSystemRX3i可编程自动化控制器(PAC)系列的通

联系人:Sunny

手机:18059884797

QQ:3095989363

邮箱:xiongbagk@gmail.com

产品详情

型号:IC695CHS007LT 可编程自动化控制器 双连接器插槽







【产品详情】





IC695CHS007是 PACSystem RX3i 可编程自动化控制器 (PAC) 系列的通用背板。此背板是七 (7) 插槽背板,预留给电源和 I/O 模块。它原生支持 PACsystem RX3i 系列的任何 IO 和选件模块以及 90-30 系列 I/O 和选件模块。


IC695CHS007插槽 0 预留用于安装 IC695 电源。插槽 1-5 是双连接器插槽,支持 PACSystem 组件(如 IC695 模块)使用的外围组件互连 (PCI) 型连接器,以及 90-30 系列模块(尤其是 IC693 和 IC694 模块)使用的串行连接器。插槽 6 是最右边也是最后一个插槽,仅支持 PCI,仅兼容 RX3i 模块。


该IC695CHS007非常适合安装空间有限的应用或远程I/O架构的实现。该模块配有位于机架左端的 24 VDC 端子排。背板接地点和集成接地条,用于连接机架托管模块的屏蔽和接地连接。插槽编号也清晰地打印到该机架上,以便相应地安装模块。


该IC695CHS007有两 (2) 个版本,特别是初始版本的 IC695CHS007-AA 和 IC695CHS007-BA 后期版本,其中包括机械增强功能,尤其是机箱的背板 PCI 连接器。


该IC695CHS007仅用于水平铸造。其他安装方向可能会影响气流并最终影响系统性能。此机架通过机箱提供的安装孔直接安装到机箱子面板上。


GE IC695CHS007背板是一种通用背板,是 GE Fanuc 设计和制造的 RX3i PACSystems 系列的一部分,是 90-30 系列系统的替代品。IC695CHS007背板的输入电压为 +24 V。用户应注意,建议的安装方法应包括水平方向和安装在最低防护等级为 IP 20(NEMA 类型 1)的防护外壳中。IC695CHS007通用背板有一个接地点,端子排位于左端。此外,背板还包括一个集成的接地条和用于配置的可见插槽编号,并为其他制造商的系统和选件模块提供支持。




型号:IC695CHS007LT 可编程自动化控制器 双连接器插槽




英文介绍







The IC695CHS007 is a universal backplane for the PACSystem RX3i Programmable Automation Controller (PAC) family. This backplane is a seven (7) slot backplane reserved for power and I/O modules. It natively supports any IO and option modules of the PACsystem RX3i series as well as the 90-30 series I/O and option modules.


IC695CHS007 slot 0 is reserved for installing the IC695 power supply. Slots 1-5 are dual connector slots that support Peripheral Component Interconnect (PCI) type connectors for PACSystem components, such as the IC695 module, and serial connectors for series 90-30 modules, especially the IC693 and IC694 modules. Slot 6, the rightmost and last slot, supports PCI only and is compatible only with RX3i modules.


The IC695CHS007 is ideal for applications with limited installation space or remote I/O architectures. The module is equipped with a 24 VDC terminal block located on the left end of the rack. The backplane ground point and integrated ground bar are used to connect the shielding and grounding connections of the rack hosting module. Slot numbers are also clearly printed to the aircraft so that modules can be installed accordingly.


The IC695CHS007 is available in two (2) versions, especially the initial version of the IC695CHS007-AA and the later version of the IC695CHS007-BA, which includes mechanical enhancements, especially the backplane PCI connector for the chassis.


The IC695CHS007 is for horizontal casting only. Other mounting directions may affect airflow and ultimately system performance. The frame is mounted directly into the case panel through the mounting holes provided in the case.


The GE IC695CHS007 backplane is a universal backplane that is part of the RX3i PACSystems family designed and manufactured by GE Fanuc and is a replacement for the 90-30 series systems. The input voltage of the IC695CHS007 backplane is +24 V. Users should note that the recommended installation method should include horizontal orientation and installation in a protective housing with a minimum protection class of IP 20 (NEMA Type 1). The IC695CHS007 backplane has one ground point and the terminal block is located on the left. In addition, the backplane includes an integrated ground bar and visible slot numbers for configuration and provides support for other manufacturers' systems and option modules.
