IC693PTM101
IC693PTM101

IC693PTM101 功率传感器模块 单相电源系统

型号:IC693PTM101功率传感器模块单相电源系统【产品详情】IC693PTM101是一种功率传感器模块,是艾默生自动化90-30系列平台的一部分,前身为G

联系人:Sunny

手机:18059884797

QQ:3095989363

邮箱:xiongbagk@gmail.com

产品详情

型号:IC693PTM101 功率传感器模块 单相电源系统







【产品详情】





IC693PTM101 是一种功率传感器模块,是艾默生自动化 90-30 系列平台的一部分,前身为 GE Fanuc Automation。该模块主要用于实现发电机与配电网之间的用电分析和电压监测。它是一种高度智能的设备,可以编程为在单模、三相模式和同步监控模式下运行,以执行各种功能。该模块安装在 Serie 90-30 底板上。它被设计为连接到电流和电位互感器进行数据计算。该模块由三 (3) 部分组成,具体为处理模块、接口板和接口电缆。它可用于星形或三角形三相电源系统或单相电源系统。该IC693PTM101可用于精确测量电压和电流的均方根 (RMS) 值,并在 15 分钟内计算功率、功率因数、频率、能量和总需求以及三相连接。从本质上讲,该模块可以涵盖功率计的功能,但是,通过增加的工作模式和功能以及直接连接到PLC的能力,使数据集成变得简单并可以轻松执行。该模块还可以执行数据报告和故障监控。它还可用于发电机-握把同步功能,并执行需求惩罚成本降低和减载要求。该IC693PTM101兼容所有类型的 90-30 系列 PLC CPU。处理器模块可以安装在任何基板上,无论是 CPU、扩展还是远程基板,为用户提供最大的灵活性,并可能消除长时间的电缆铺设。


IC693PTM101模块是GE发那科制造的单相功率变送器模块。它是一种 90-30 GE 系列设备,广泛用于工业自动化。它带有一个处理模块、一个接口板和一根接口电缆。它用于在功率变送器和输入变压器之间建立连接。该模块生成的数据可由PLC进一步用于报告、故障监控和减载/减载应用。IC693PTM101模块的输入电压额定值在 10 到 120 伏交流电之间。它的额定电流在 0 到 7.5 安培之间。传感器模块的额定频率为 35 至 70 赫兹,具有 0 个输出。模块的背板隔离电压为 1500 伏。它散发的总功率为 4 瓦作为热量。




型号:IC693PTM101 功率传感器模块 单相电源系统






英文介绍





The IC693PTM101 is a power sensor module that is part of Emerson Automation's 90-30 series platform, formerly known as GE Fanuc Automation. The module is mainly used to realize the power analysis and voltage monitoring between the generator and the distribution network. It is a highly intelligent device that can be programmed to operate in single mode, three-phase mode, and synchronous monitoring mode to perform a variety of functions. The module is mounted on the Serie 90-30 baseplate. It is designed to be connected to current and potential transformers for data calculation. The module consists of three (3) parts, specifically a processing module, an interface board and an interface cable. It can be used in star or triangular three-phase power systems or single-phase power systems. The IC693PTM101 can be used to accurately measure root mean square (RMS) values of voltage and current and calculate power, power factor, frequency, energy and total demand as well as three-phase connections in 15 minutes. In essence, the module can cover the functions of the power meter, however, with the added operating modes and functions and the ability to connect directly to the PLC, the data integration is simple and can be easily performed. The module can also perform data reporting and fault monitoring. It can also be used for generator-grip synchronization functions and to perform demand penalty cost reduction and load reduction requirements. The IC693PTM101 is compatible with all types of 90-30 series PLC cpus. The processor module can be installed on any substrate, whether CPU, expansion or remote substrate, providing maximum flexibility to the user and potentially eliminating long hours of cable laying.


The IC693PTM101 module is a single phase power transmitter module manufactured by GE Fanuc. It is a 90-30 GE series device that is widely used in industrial automation. It comes with a processing module, an interface board and an interface cable. It is used to establish a connection between the power transmitter and the input transformer. The data generated by this module can be further used by the PLC for reporting, fault monitoring and load/load shedding applications. The input voltage of the IC693PTM101 module is rated between 10 and 120 volts AC. Its current rating is between 0 and 7.5 amps. The sensor module has a rated frequency of 35 to 70 Hz with 0 outputs. The backplane isolation voltage of the module is 1500 volts. It emits a total power of 4 watts as heat.




型号:IC693PTM101 功率传感器模块 单相电源系统
