IC200ALG262J 差分电流模块 具有 8 个通道

☆型号：IC200ALG262J 差分电流模块 具有 8 个通道

【产品详情】

产品描述

IC200ALG262 是 GE Versamax 的 15 位差分电流模块，具有 8 个通道。 该模拟输入模块提供与八个模拟电流输入的接口，这些输入从背板电源接收电源。这意味着模块操作不需要外部电源。但是，用户收发器的电源需要来自外部电源。

该IC200ALG262具有一组 8 个差分输入通道，具有 15 位转换器分辨率。CPU 或 NIU 对本机执行智能处理，因为该模块提供 8 字模拟输入数据。该装置报告现场侧电路的电源丢失故障和每个通道的开路故障，但仅在 4-20mA 模式下。载波端子上的跳线可用于根据需要配置此范围或0-20mA输入范围，或者缺少跳线电缆将允许模块使用4-20mA范围。此外，LED 灯指示电源和正常工作。

首次安装 IC200ALG262 模块时，请仔细检查所有部件是否损坏。请勿使用损坏的部件，因为这可能会影响整体功能。模拟通道连接应使用屏蔽双绞线电缆创建，电缆在源设备处接地。但是，如果无法在源端接地，则 I/O 模块的接地是合适的，可以使用辅助 I/O 端子完成。如果使用此选项，则可以在连接到 I/O 载体的辅助 I/O 端子上进行屏蔽连接。如果需要额外的连接，可以使用辅助 I/O 端子排。

☆型号：IC200ALG262J 差分电流模块 具有 8 个通道

【英文介绍】

Product description

The IC200ALG262 is a 15-bit differential current module for GE Versamax with 8 channels. The analog input module provides an interface to eight analog current inputs that receive power from the backplane power supply. This means that no external power supply is required for module operation. However, power to the user transceiver needs to come from an external power source.

The IC200ALG262 has a set of eight differential input channels with a 15-bit converter resolution. The CPU or NIU performs intelligent processing on the machine because the module provides 8-word analog input data. The device reports power loss failures in field side circuits and open circuit failures in each channel, but only in 4-20mA mode. The jumper on the carrier terminal can be used to configure this range or the 0-20mA input range as needed, or the absence of a jumper cable will allow the module to use the 4-20mA range. In addition, LED lights indicate power and normal operation.

When installing the IC200ALG262 module for the first time, check whether all components are damaged. Do not use damaged parts, as this may affect the overall function. Analog channel connections should be created using shielded twisted pair cables that are grounded at the source device. However, if it is not possible to ground at the source, then the grounding of the I/O module is appropriate and can be done using the auxiliary I/O terminal. If this option is used, masking connections can be made on the secondary I/O terminals connected to the I/O carrier. If additional connections are required, an auxiliary I/O terminal block can be used.
