IS220PSCAH1A 336A4940CSP9 串行 Modbus 通信 串行收发器通道

☆型号：IS220PSCAH1A 336A4940CSP9 串行 Modbus 通信 串行收发器通道

【产品详情】

IS220PSCAH1A I/O 包用于串行 Modbus 通信。该套件是为通用电气的 Mark VIeS 控制系统设计的。使用此套件时，它可以在多达两个输入输出以太网网络和一个串行通信板之间提供接口。该板具有六个可单独配置的串行收发器通道，可用于 RS485 半双工、RS232 和 RS422 标准。为PSCA电池组供电所需的输入通过三针电源输入和双RJ45以太网连接器发送。

IS220PSCAH1A包上有一个串行Modbus主站服务，它具有许多不同的功能，其中一些功能如下：

RTU的

数据位：7、8

32 位数据字排序

奇偶校验：偶数、无、奇数

车站地址

这些功能用于PSCA包上的六个可配置端口。可以在端口级别完成配置。借助 PSCA，套件上的两个以太网端口可用于帮助支持以太网 Modbus 主站协议;请注意，此配置仅在单工网络上使用时才会发生。

☆型号：IS220PSCAH1A 336A4940CSP9 串行 Modbus 通信 串行收发器通道

【英文介绍】

The IS220PSCAH1A I/O package is used for serial Modbus communication. The kit is designed for General Electric's Mark VIeS control system. When used with this suite, it can provide an interface between up to two input-output Ethernet networks and a serial communication board. The board features six individually configurable serial transceiver channels that can be used with RS485 half-duplex, RS232 and RS422 standards. The input needed to power the PSCA battery pack is sent via a three-pin power input and dual RJ45 Ethernet connector.

There is a serial Modbus master service on the IS220PSCAH1A package, which has many different features, some of which are as follows:

RTU

Data bits: 7, 8

32-bit data word sort

Parity check: even, none, and odd

Station address

These functions are used for the six configurable ports on the PSCA package. This can be done at the port level. With PSCA, two Ethernet ports on the suite can be used to help support the Ethernet Modbus master protocol; Note that this configuration only occurs when used on a simplex network.
