369-HI-R-0-0-0 电机管理继电器 跳闸计数器

☆型号：369-HI-R-0-0-0 电机管理继电器 跳闸计数器

【产品详情】

GE Multilin 的 369-HI-R-0-0-0 电机管理继电器设计用于控制和保护大中型电机。369 包括以下保护功能：欠压自动重启、反向电源、起动器故障、kVA 需求、kvar 需求、kW 需求、电流需求、反旋检测、自检/维修、跳闸计数器、RRTD 通信丢失、断路/开路 RTD、短路/低温 RTD、环境 RTD、加速计时器、机械干扰、 和更多。

369-HI-R-0-0-0 是由 GE Multilin 制造的电机管理继电器。 控制电源为 50-300 VDC / 40-265 VAC。该继电器有 12 个可选的 RTD 输入。本机不包括测光或后旋检测。没有可选的光纤端口。该继电器为三相电机及其相关系统提供保护和监控。369 可以“学习”单个电机参数，并适应各个应用。为了提高继电器的保护能力，用户可以调整电机浪涌电流、冷却速率和/或加速时间。如果您对此部件或系列有任何疑问，请联系 AX Control。

继电器的保护功能包括欠压自动重启、反向功率、启动器故障、kVA 需求、kvar 需求、kW 需求、电流需求、反旋检测、自检/服务、跳闸计数器、RRTD 通信丢失、断开/开路 RTD、短温/低温 RTD、环境 RTD、加速计时器、机械干扰、 重启块（后旋定时器）、启动抑制（可用热容量）、热容量、无功功率、通用开关、差分开关、锁定、过/欠频、报警、每小时启动/启动间隔时间、过压保护、功率因数、过载保护、接地故障和接地故障备份、短路和备份、 定子RTD、电压反相、电流不平衡保护、轴承RTD、欠流/欠功率保护、欠压保护和速度开关。

☆型号：369-HI-R-0-0-0 电机管理继电器 跳闸计数器

【英文介绍】

GE Multilin's 369-HI-R-0-0-0 motor management relay is designed to control and protect large and medium sized motors. 369 includes the following protection functions: Automatic undervoltage restart, reverse power supply, starter failure, kVA requirement, kvar requirement, kW requirement, current requirement, backspin detection, self-test/repair, trip counter, RRTD communication loss, open/open RTD, Short/low temperature RTD, Environmental RTD, acceleration timer, Mechanical interference, and more.

The 369-HI-R-0-0-0 is a motor management relay manufactured by GE Multilin. Control power supply is 50-300 VDC / 40-265 VAC. The relay has 12 optional RTD inputs. This unit does not include metering or backspin detection. No optical fiber port is available. The relay provides protection and monitoring for three-phase motors and their associated systems. The 369 can "learn" individual motor parameters and adapt to individual applications. To improve the protection of the relay, the user can adjust the motor surge current, cooling rate and/or acceleration time. If you have any questions about this part or series, please contact AX Control.

Relay protection features include automatic undervoltage restart, reverse power, starter failure, kVA requirement, kvar requirement, kW requirement, current requirement, backspin detection, self-test/service, trip counter, RRTD communication loss, open/open RTD, short temperature/low temperature RTD, ambient RTD, acceleration timer, mechanical interference, and other functions. Restart block (backspin timer), Start suppression (available heat capacity), heat capacity, reactive Power, Universal switch, Differential Switch, Lock, over/under frequency, alarm, start/start interval per hour, overvoltage protection, power factor, overload protection, ground fault and ground fault backup, Short circuit and backup, Stator RTD, voltage reversal, current unbalance protection, bearing RTD, undercurrent/underpower protection, undervoltage protection and speed switches.

☆型号：369-HI-R-0-0-0 电机管理继电器 跳闸计数器
